China 5mm F2.8-F16 Fixed Focal Length Lenses for sale

5mm F2.8-F16 Fixed Focal Length Lenses

Price Negotiable

Price: Negotiable

MOQ: 1 piece

Delivery Time: 7 work days at the soonest

Brand: OPT

Product Description

Cobra Series Fixed Focal Length Lenses Focal Length 35mm F2.8-F16 WD 210-∞ 0.06kg OPT-COB3528

Product Features

◆ The F/# aperture is F2.8-F16.

◆ It is designed with low distortion and TV distortion＜0.2%

◆ It can support high relative Illuminance and get high evenness image by matched with cameras.

◆ The OPT-COB3528 working distance is 210-∞.
◆ The diameter of image circle :11mm.

◆ Filter thread: M27*P0.5.

◆ Cobra series fixed focal length lenses OPT-COB3528 focal length is 35mm.

◆ Back focal length (mm): back focal length is 18.39mm when its working distance is 210mm; back focal length is 12.87mm when its working distance is infinity.

◆ Weight of OPT-COB3528 fixed focal length lens is 0.06kg.

◆ The cobra series fixed focal length lenses' resolution is 2.2µm.

◆ TV distortion is less than 0.2% at working distance of 350mm.

◆ Magnification at MOD is 0.161X at working distance of 210mm.

◆ The chief ray angle is＜5°.

Model Explanation

OPT-COB2528

OPT: Brand name

C: C-Mount

OB: Cobra series lenses

25: Focal length: 25mm

28: F#: 2.8

Specifications

Product Name	Fixed Focal Length Lenses of Cobra Series
Model	OPT-COB3528
Focal Length	35mm
Aperture range	From F2.8 to F16
Working Distance(mm)	210mm-∞
TV Distortion(%)	Less than 0.2% at working distance of 350mm
Back focal length (mm)	18.39mm when its working distance is 210mm 12.87mm when its working distance is infinity
Weight(kg)	0.06kg
Image circle Ø (mm)	11mm
Resolution (µm)	2.2µm
Chief Ray Angle	Less than 5°
Magnification(x) at MOD	0.161X at working distance of 210mm
