China F2.5~F22 WD 600mm-∞ 50mm Fixed Lens 0.11kg Machine Vision Components for sale

F2.5~F22 WD 600mm-∞ 50mm Fixed Lens 0.11kg Machine Vision Components

Price Negotiable

Price: Negotiable

MOQ: 1 piece

Delivery Time: 7 work days at the soonest

Brand: OPT

Product Description

5MP Fixed Focal Length Lenses F2.5~F22 WD 600-∞ Focal Length 50mm 0.11kg OPT-C5025-5M

Product Features

◆ The F/# aperture is F2.5~F22

◆ High resolution: compatible with 5MP industrial cameras of ≥ 3.45μm pixel size and max. 2/3" sensor; up to 140 lp/mm full FOV resolution.(OPT-C0420-5M/OPT-C0620-5M: Compatible with 3MP cameras of max. 1/2" sensor)

◆ Low distortion: total distortion < 0.7%, min. distortion as low as 0.02%(OPT-C0420-5M & OPT-C0620-5M are not included.).

◆ The OPT-C5025-5M working distance is 600mm-∞.

◆ Filter thread is M30.5*P0.5.

◆ OPT-C5025-5M fixed focal length lenses focal length is 50mm.

◆ Back focal length (mm): back focal length is 13.19mm.

◆ Weight of OPT-C5025-5M fixed focal length lens is 0.11kg.

◆ The sensor format of OPT-C5025-5M is 1/3″ | 1/2.5″ | 1/1.8″ | 2/3″.

◆ The distortion is less than 0.05%.

◆ FOV angle (H×V×D) is 5.3° | 6.2° | 7.9° | 9.1°, 3.9° | 4.6° | 5.9° | 7.7°, 6.6° | 7.7° | 9.8° | 12.0°.

Model Explanation

OPT-C5025-5M

OPT: Brand name

C: C-Mount

50: Focal length: 50mm

25: F#: 2.5

5M: 5M pixel

Specifications

Product Name	5MP Fixed Focal Length Lenses
Model	OPT-C5025-5M
Focal Length	50mm
Aperture range	F2.5~F22
Working Distance(mm)	600-∞
Filter thread(mm)	M30.5*P0.5
Distortion(%)	Less than 0.05%
Back focal length (mm)	13.19mm
Weight(kg)	0.11kg
Sensor format	1/3″ \| 1/2.5″ \| 1/1.8″ \| 2/3″
FOV angle (H×V×D)	5.3° \| 6.2° \| 7.9° \| 9.1° 3.9° \| 4.6° \| 5.9° \| 7.7° 6.6° \| 7.7° \| 9.8° \| 12.0°
