Medical Bedside Monitor Spare Parts Mindray PM8000 PM-8000 Patient Monitor Rotary Knob

Medical Bedside Monitor Parts Mindray PM8000 PM-8000 Patient Monitor Rotary Knob

Mindray PM8000 PM-8000 Patient Monitor Rotary Knob


► Brief Introduction

The rotary knob on the Mindray PM8000 PM-8000 patient monitor is a feature that allows users to easily navigate through menus and make selections. It is a physical knob that can be rotated clockwise or counterclockwise to scroll through options, and pressed to confirm selections. This feature provides a tactile and efficient way for users to interact with the patient monitor and adjust settings as needed.

► Method to use the knob to operate on the screen:

The rectangular mark on the screen that moves with the rotation of the knob is called “cursor”. Operation can be performed at any position at which the cursor can stay. When the cursor is in the waveform area, the user may immediately modify the current setup. When the cursor is in the parameter area, the user may open the setup menu of the corresponding parameter module so as to set up the menu items of the module.

Operating method:

• Move the cursor to the item where the operation is wanted
• Press the knob
• One of the following four situations may appear:

1. The cursor with background color may become into the frame without background color, which implies that the content in the frame can change with the rotation of the knob.
2. Menu or measuring window may appear on the screen, or the original menu is replaced by the new menu.
3. A check mark “√” appears at the position, indicating that the item is confirmed.
4. The system immediately executes a certain function.

► Functional

The square frame that moves when the knob is being turned is called "cursor". Operation can be executed at any place where the cursor can stay. When no menu is displayed, turning the knob clockwise can select following hot keys:

• Channel 1 ECG lead
• Channel 1 ECG gain
• ECG filter
• Channel 2 ECG lead
• Channel 2 ECG gain
• IBP Label
• ECG menu
• SpO2 menu
• NIBP menu
• IBP menu
• RESP menu
• TEMP menu

When the current cursor is placed at any of the first six items, the user can change the current settings.

When at any of the last six items, related parameter menu could be called up for setting changes.

► Specification

► Warranty Guarantee

Under normal conditions, whether our new or used items usually comes with a three-month warranty period. That is to say you are allowed to change or get the machines repaired under guarantee if you find there is any problem about the product you purchased. However, take it easy please. We hope you will be pleased with our products and service down to the ground. Moreover, we have a lot of confidence to satisfy you as our goods are all in perfectly high quality. Years of sales experience makes us handle this sort of issues skillfully. Customers’ satisfaction is the goal that we are always pursuing.

If you want to explore more details about Mindray PM8000 PM-8000 Patient Monitor Encoder E204460 , please let us know.

Thank you for your time and interest.
