GE Mac1200ST ECG machine is suitable for hospital patients and private clinics

GE's twelve-lead MAC1200 electrocardiograph highlights its high performance and user-friendly interface, and provides a superior cost performance. The standard built-in battery allows you to use it anytime and anywhere. Clear 3-channel graphic display with easy-to-understand instructions for the operator.

Scope of application:

MAC1200 is a static electrocardiogram system that can complete all operations with just one button, so it is particularly suitable for private clinics, emergency rooms or

Compatibility:

MAC 1200/1200 ST is printed with the CE mark CE-0459, which is GMED, indicating that it is consistent

with the Council Directive 93/42/EEC on medical devices and meets the basic requirements of Appendix

I of this manual.

Other directives or all standards to which this product complies are listed in the overview of the operating instructions for the product below on

this page.

The country of manufacture is printed on the device label.

The radio interference protection level of this product is Class A, in accordance with EN 55011.

This product complies with the requirements of the EN 60601-1-2 "Electromagnetic Compatibility - Medical Equipment" standard.

Compared with previously configured equipment, the safety and effectiveness of this equipment have been proven. Although all

standards that can be applied to equipment currently on the market may not be applicable to previous equipment (such as

electromagnetic compatibility standards), such equipment will not cause damage to the safe and effective use of previously configured

equipment. See user information

exception:

MAC 1200/1200 ST EMC (Electromagnetic Compatibility): Immunity Performance

Users should be aware that known RF sources, such as radio or television stations and handheld or mobile two-way

radios, need to be considered when installing medical equipment or systems.

Note that adding accessories or modifying medical equipment or systems may degrade EMI performance. Changes in system settings

should be consulted with qualified personnel.

Product configuration:

Technical Parameters:

1. GE internationally renowned brand

2. ECG input Synchronous 12-lead ECG collection and printing

3. Input impedance: ≥100MQ

4. Withstand polarization voltage: ±300mV

5. Input protection function: operation protection

6. Sensitivity selection 2.5, 5, 10, 20, 40mm/mv

7. Common mode rejection ratio: ≥60dB

8. Frequency response: 0.04-150Hz (-3db)
