Philiph TC10 ECG machine LCD

Display Assembly 453564413761

► The features of Philiph TC10 ECG machine LCD Display Assembly 453564413761

Philiph TC10 ECG machine LCD Display Assembly 453564413761 typically includes features such as:

--High-Resolution Display: Clearly displays ECG waveforms and patient data.

--User Interface: Touchscreen functionality or physical buttons for easy navigation between different functions and settings.

--Real-Time Data Display: View ECG readings, heart rate, and other essential cardiac metrics in real-time to make immediate, informed clinical decisions.

--Durability and Reliability: Designed to meet the demands of clinical environments, ensuring long-term performance.

► Touch Screen Display

800 x 480 pixel resolution VGA with 16-bit/pixel color depth l

5-wire, resistive touch screen l

15.4 cm wide x 8.6 cm high (7-inch diagonal) color liquid crystal touch screen display with LED backlight

► Display Accuracy l

The accuracy of the ECG signals are within +/- 5% (or +/- 40 µV whichever is greater), over a range of 0 to +/- 5 mV, in the presence of common

mode DC offset voltages of +/- 300 mV. The cardiograph performance is tested to comply with the accuracy requirements over the dynamic

ranges and frequency ranges specified in the IEC 60601-2-25:2011 standard.

► Specification of Philiph TC10 ECG machine display assembly 453564413761

► About Philiph TC10 ECG Machine

The Philiph Pagewriter TC10 with 7 "touch screen and 12 leads is a portable, user-friendly ECG recorder with integrated thermal printer and

replaceable battery, supporting advanced cardiography, LAN / WLAN connectivity, and the advanced Philiph DXL ECG algorithm. The portable

ECG Pagewriter TC10 is thus a cost-effective solution if efficient processes are required.

► Photo of Philiph TC10 ECG Machine LCD Display Assembly 453564413761

Thank you so much for your attention .If you're interested in ,feel free to contact us .Thank you .
