Edan F6 Fetal Monitor Motor Assembly PM42S-096-XHG6 TA7302 Plastic Patient Monitor Black and White Color Spare Parts
Edan F6 Fetal Monitor Motor Assembly PM42S-096-XHG6 TA7302 Plastic Patient Monitor Black and White Color Spare Parts
■ Product Describe
Edan F6 Fetal Monitor Motor Assembly, model number PM42S-096-XHG6 TA7302, is the core component of the device. This motor assembly is located in the printing unit of the device and is responsible for converting the received electrical energy into mechanical movement to drive the printer.
One of its design features is low noise, because F6 Fetal Monitor is a professional medical device, usually used in hospitals, and usually runs silently to avoid disturbing medical staff and patients.
This accessory can accurately control the printing content by receiving pulse signals or encoder feedback.
At the same time, this accessory has wear-resistant characteristics and can adapt to the use of high-frequency words (such as long-term monitoring in the delivery room).
■ Functions
The main function of this component is to drive the device printing module. As a multifunctional medical device, F6 Fetal Monitor has its own printing function and is compatible with 152mm and 150mm US or international standard thermal printing paper. The recorded information includes patient information, fetal heart rate waveform, uterine contraction waveform, fetal movement, etc. This accessory is responsible for controlling paper feeding and print head movement to ensure that the received patient data can be accurately output for clinicians to diagnose.
■ Product Pictures
■ Functions
1. Mechanical protection
Dust and dirt prevention: The design of this accessory can cover the adjustment roller and shaft of the display screen, which can effectively prevent dust, liquid or obligation from entering the device, avoiding the device from getting stuck or damaged.
Anti-touch: Prevent medical staff or patients from accidentally touching the internal precision parts (such as gears and bearings).
2. Auxiliary screen adjustment
Cooperate with the display screen roller to realize the multi-angle adjustment function of the display screen, facilitate the work of medical staff and improve clinical efficiency.
3. Appearance integration
Hide the internal structure while keeping the appearance of the device clean, increasing the overall beauty of the device.
■ Products Parameters
| Products Name | Motor Assembly |
| Part Number | PM42S-096-XHG6 TA7302 |
| Adaption Machine | F6 Fetal Monitor |
| Brand | Edan |
| Condition | Used-Good |
| Material | Plastic |
| Delivery Time | 3-5 Working Days |
| Color | Black and White |
| More Details | Contact CWT Technology HK Limited |
■ Fault manifestations and impacts
1. Motor stall
Motor stalling can cause other components to fail, such as printer failure.
2. Motor abnormal noise or vibration
May be caused by bearing wear or gear misalignment.
If abnormal noise or vibration occurs, please stop using the machine in time to avoid more serious impact.
3. Overheat protection triggering
Motor overload operation may trigger thermal protection and the device will automatically power off.
Please pay attention to the motor status and perform regular maintenance and inspection.
■ Daily maintenance
1. Clean the dust of the module regularly (especially printer paper scraps) to avoid blocking the motor operation.
2. Avoid frequent overload operations (such as continuous printing of large reports).
If you need repair or replacement of accessories, please contact CWT Technology HK Limited.
