Philipph M1941A Spo2 Extension Cable 8Pin 2m 989803105681 New Original Medical Accessories

Philipph M1941A Spo2 Extension Cable 8Pin 2m 989803105681 New Original Medical Accessories

► Brief Introduction

Philipph M1941A Spo2 Extension Cable 8 Pin 2m 989803105681
2m Extension Cable for Philipph SpO2 Pulse Oximeter, Genuine Medical Accessory, M1941A / 989803105681
Philipph Healthcare Part Number: M1941A / 989803105681
Length: Approx. 2m (6.56 ft)
Weight: Approx. 236g

The Philipph M1941A Extension Cable is an 8-pin to 8-pin input connector for 8-pin sensors and Philipph Quick Connect. Compatible with a wide range of PHiliph products. Suitable for multi-patient use and non-sterile. The cable has been tested multiple times to ensure it can withstand the pulling and twisting that comes with heavy use. The Philipph M1941A Spo2 Extension Cable can be used with other consumables (M1191B, M1192A, M1193A, M1194A, M1195A, M1196A, M1196S).

►Advantages:
1. Accurate and reliable monitoring data
2. Avoid device interface damage or performance degradation due to the use of inferior accessories.
3. Original certified accessories, original accessories are strictly tested to ensure the best working state with the host equipment.

► Specification

►Core installation steps:

1. Turn off the monitor power:

Before making any connection operations, be sure to turn off the power of the PHiliph patient monitor to be connected (such as the IntelliVue series, etc.). This is to prevent damage to the device due to electrical short circuits or accidental connection errors.

2. Identify the interface:

One end of the extension cable (device end): This interface (usually a female connector with a hole) needs to be connected to the SpO2 module port on the monitor body.

The other end of the extension cable (probe end): This interface (usually a male connector with a pin) needs to be connected to the original PHiliph SpO2 probe cable (usually an 8-pin probe).

Original probe cable: The original SpO2 probe cable ends with a sensor (clipped on the patient's finger, toe or patch).

3. Connect the extension cable to the monitor:

Align the extension cable interface marked with "device end" or similar (or without a label but the structure corresponds to the monitor port) with the SpO2 module output port on the monitor.

Carefully align the shape and orientation of the plug and socket. 8-pin connectors usually have a foolproof design (a ridge or groove) to ensure perfect alignment.

Insert smoothly and vertically until you hear or feel a "click" indicating that the connector is fully seated and locked. Do not force it! If you feel a lot of resistance, stop immediately and check the alignment.

4. Connect the original probe cable to the extension cable:

Insert the end of the original SpO2 probe cable (usually an 8-pin male connector) into the connector (usually an 8-pin female connector) marked with "probe end" or similar (or the other end) of the extension cable.

Again, carefully align the shape and orientation to ensure that the foolproof design matches.

Insert smoothly and vertically until you hear or feel a "click" indicating that it is fully locked. Do not force it!

5. Connect the probe to the patient:

According to standard operating procedures, correctly and comfortably connect the SpO2 sensor (clip or patch) to the appropriate part of the patient (such as fingers, toes, forehead, etc.). Ensure the sensor is well seated and not overly compressed or loose.

If you want to explore more details about Philipph M1941A Spo2 Extension Cable 8Pin 2m 989803105681 New Original Medical Accessories, please let us know. Looking forward to receiving your early inquiry.
