Biolight BLT Q5 Patient Monitor USB Network Card Interface Board Wiring 11-056-0007

Biolight BLT Q5 Patient Monitor USB Network Card Interface Board Wiring 11-056-0007


► Brief Description


USB Network Card Interface Board Wiring, Model: 11-056-0007, the wiring is for the Biolight BLT Q5 monitor. Interface type: USB Type-A female + RJ45 network interface. Data transfer rate: USB 2.0 (480 Mbps) / 10/100M. Operating temperature: 0°C to 50°C. This black cable has connectors at both ends; one end connects to the network card, and the other end connects to the motherboard. Data is transferred from the network card to the Biolight BLT Q5 monitor's motherboard via this cable.

►Functions and Uses:

1. Network Connectivity: Connecting the Q5 monitor to the hospital's local area network (LAN) via USB Network Card Interface Board Wiring 11-056-0007 allows real-time patient vital signs data to be transmitted to the central monitoring system at the nurses' station.

2. Data Archiving: Monitoring data can be continuously transmitted to the hospital's clinical information center or electronic medical record system, enabling automatic and complete archiving of patient monitoring records.

3. Remote Viewing: Authorized doctors or nurses can remotely view real-time monitoring waveforms and parameters for a designated bedside patient on computers in offices, duty rooms, etc., using a web browser.

4. USB Host Functions:

Data Export: By inserting a USB flash drive, trend data, event reviews, ECG segments, etc., over a period of time can be exported to a removable storage device. This data can be used for consultations, report generation, or backup.


► Specifications



►Detailed Photos


►USB Network Card Interface Board Wiring Application Scenarios

1. Inpatient Wards: Connect to the central monitoring system for continuous monitoring and alarms.

2. Operating Rooms: Transmit critical vital signs data during patient transfer to the next department.

3. Intra-hospital Transfers: While wireless communication may be used during transport, network access is established upon returning to the patient's fixed bed.


►Why Choose USB Network Card Interface Board Wiring 11-056-0007?

1. Original Manufacturer Compatibility Optimization: Deeply optimized for the hardware architecture and data processing characteristics of the BLT Q5 monitor, ensuring the highest standards of signal integrity, data synchronization accuracy, and system stability.

2. Stable Long-Term Operation: With a mean time between failures (MTBF) exceeding 50,000 hours, designed for 24/7 continuous operation in medical environments, its reliability has been rigorously verified.

3. Comprehensive Technical Support: Provides technical support from installation and commissioning, system integration to routine maintenance, ensuring your monitoring system is always in optimal working condition.

►How to Install a USB Network Card Interface Board Wiring

1. Power off the Q5 monitor.

Locate the interface on the network card and remove the protective cover from the cable connector. Align the connector's pins with the center hole of the network card interface and gently insert it.

2. Secure the network card.

If the network card comes with a desktop stand, insert the network card into the stand.

Use the included USB extension cable to connect the stand's USB port to the device's USB port.

3. Check that all cables and interfaces are secure. After confirming there are no problems, power on and test.


If you want to explore more details about Biolight BLT Q5 Patient Monitor USB Network Card Interface Board Wiring 11-056-0007 , please contact me at any time, looking forward to your early inquiry.
