Mindray AG Module Infrared Board 6800-30-50810 051-000581-00 for BeneVision Series Anesthesia /Monitors
Mindray AG Module Infrared Board
Mindray AG Module Infrared Board 6800-30-50810 051-000581-00 for BeneVision Series Anesthesia /Monitors
► Brief Description
Mindray's Infrared Board is the core component of its AG (Anesthetic Gas Module). It accurately identifies and analyzes the composition of the patient's exhaled gases during surgical anesthesia monitoring. This board receives raw signals from an infrared light source and detector, converts them into precise gas concentration readings using sophisticated algorithms, and transmits them to the host unit for display on a screen for the user.
► Working Principle
- Light Source Emission: An infrared light source emits infrared light of a specific wavelength, which passes through the gas sampling chamber.
- Gas Absorption: Different anesthetic gases absorb infrared light of specific wavelengths.
- Signal Reception and Conversion: Sensors on the infrared detection board receive the light signal passing through the gas and convert it into a weak electrical signal.
- Signal Processing: The core circuitry on the detection board amplifies, filters, and digitizes these electrical signals.
- Data Output: The processed digital signal is transmitted to the main control board of the AG module, where it ultimately calculates the concentration of various anesthetic gases.
► Detailed Photos
► Common Faults
Mindray's AG Module Infrared Board 6800-30-50810 051-000581-00 is crucial for maintaining the normal operation of the anesthetic gas monitoring system. When your equipment experiences gas monitoring anomalies, accurately diagnosing and replacing this core component is the most effective way to quickly restore equipment functionality and ensure the normal operation of the operating room.
Common Faults:
1. Error messages appear during equipment self-test;
2. Data drift or failure to return to zero;
3. Weak signal or no waveform;
4. The host cannot recognize the anesthetic gas module.
► FAQ
|
Q1: Is your board truly compatible with our equipment? |
|
A1: To ensure accuracy, please be aware of the subtle differences in model numbers. Please look for model numbers 6800-30-50810 and 051-000581-00. Before purchasing, please verify the label on the back of the device and provide the device serial number for final confirmation. |
|
Q2: Can you guarantee that it will be 100% usable? |
|
A2: Yes. After undergoing more than 48 hours of aging and functional testing, it is guaranteed to be ready to use immediately upon installation. |
|
Q3: How about the warranty. |
|
A3: We provide 90 days warranty. |
|
Q4: What if I don't know how to install it? |
|
A4: Please feel free to contact us; we provide installation guidance and troubleshooting advice. |
