Biocare ECG-1210 ECG Machine Mainboard 02040144-01 Green Color Medical Device

Biocare ECG-1210 ECG Machine Mainboard 02040144-01 Green Color

► Brief Description


The Mainboard 02040144-01 is a crucial component of the ECG-1210 ECG Machine. It's a green metal board with numerous interfaces for connecting various modules of the ECG machine. Several black button batteries are also located on the mainboard. The Mainboard 02040144-01 is the ECG-1210's signal processor, receiving the weak, raw ECG signals from the leads. The sophisticated analog front-end circuitry on the mainboard amplifies and filters these signals, effectively suppressing external interference and providing a "clean" signal source for subsequent digital analysis.

►Mainboard 02040144-01 Functions:

1. The mainboard receives weak biosignals from the leads and amplifies and converts them into high-precision digital signals for analysis by the microprocessor.

2. Manages the coordinated operation of all hardware components (such as the thermal printer, keyboard, monitor, and SD card storage).

3. User Interaction and Display: Displays real-time, clear information such as 12-lead ECG waveform, heart rate, lead status, battery level, time, and date.

4. Data Storage and Output: Manages the built-in memory and/or external SD card for storing patient ECG data, measurement results, and reports.

► Specifications

►Installation Steps

1. Disconnect Power and Remove the Casing

First, turn off all power. Use a screwdriver to unscrew all the screws on the bottom casing. Carefully remove the bottom casing. After removing the bottom casing, you will see the motherboard.

2. Remove the Old Motherboard

Before proceeding, use your phone to take clear pictures of all the connecting wires, ribbon cables, and screw positions on the motherboard from multiple angles. Disconnect all the ribbon cables from the motherboard and carefully remove the old motherboard.

3. Install the New Motherboard 02040144-01

Carefully place the new motherboard into the monitor casing, aligning all the positioning holes and connectors, and tighten all the fixing screws to ensure the motherboard is stable and does not wobble.

According to the photos you took earlier, reconnect all the ribbon cables and connectors to their corresponding interfaces.

Connect the power connector.

4. Assembly and Testing

Before reattaching the casing, carefully check that all connections are secure and correct.

Turn on the device for testing.

►Warning

Motherboard installation must be performed by a professional engineer, and an anti-static wrist strap must be worn.
