Biolight BLT Q5 Patient Monitor Alarm Indicator Board Connector Cable 11-056-0001 Replacement Parts

Biolight BLT Q5 Patient Monitor Alarm Indicator Board Connector Cable 11-056-0001 Replacement Parts

Description

This connection cable is the Biolight Q5 monitor alarm indicator board connecting cable. Its main purpose is to connect the monitor mainboard and the alarm indicator board, and is responsible for transmitting the patient's ECG signal, respiratory signal and other physiological data to the monitor mainboard in real time. When the patient's heart rate is abnormal, such as too fast, too slow or an irregular heartbeat, the connecting cable will quickly transmit these abnormal electrical signals to the host. After analysis by the host, an audible and visual alarm will be triggered through the alarm indicator board to remind medical staff or family members to handle it in a timely manner.

Installation Steps:

Tip: Before starting operation, be sure to disconnect the power supply of the monitor, including unplugging the power cord and removing the battery, and wear an anti-static bracelet to prevent short circuit or electric shock during operation.

1. Use a suitable screwdriver to remove the retaining screws from the monitor back cover and carefully remove the back cover to expose the internal components.

2. Find the cable connecting the alarm indicator board and the main board inside the device.

3. Gently open the buckle (locking piece) at the cable interface, and then carefully pull out the cable from the interface.

4. Align one end of the new cable with the motherboard interface, insert it smoothly, and then press the buckle to ensure a secure connection. Repeat the above steps to connect the other end to the alarm indicator board.

5. Before completely reinstalling the casing, it is recommended to connect the power supply and turn it on to check whether the alarm indicator function returns to normal. After the test is completed, the shells can be combined to complete the installation.

Warranty

Warranty period: 90 days

We provide warranty for both new and used equipment. Different equipment has different warranty periods. You can contact us to check the warranty details.

Delivery Details

Express delivery method: DHL, FedEx, UPS, etc.

Once payment is completed, we will immediately deliver the product to you quickly and safely. And the delivery date is about 3-5 working days, the shipping cost depends on your country and region.

If your delivery date is longer than expected, or you want to know the shipping details, you can contact us at any time.

Quality

Whether it is new equipment or old equipment, our engineers will conduct a comprehensive inspection before arranging delivery, and we have a 3 month warranty period, so you can purchase with confidence.

Warning

1. It's must use the correct electrical outlet to avoid damage or malfunction.

2. Try to avoid long-term storage, especially in high temperature and high humidity environments.

3. Do not use high-temperature, high-pressure vapour or ionizing radiation as disinfection methods.

4. Do not use chloric disinfectant such as chloride, sodium hypochlorite etc.

5. Please keep it away from water and fire.

We also provide other medical equipment and accessories. If you have any other needs or any questions about this product, please feel free to contact us, we will reply you as soon as possible.
