EDAN F2 Fetal Monitor Display Screen Housing Fixing Shaft Hinge Assembly For Heart Rate Monitor

EDAN F2 Fetal Monitor Display Screen Housing Fixing Shaft Hinge Assembly For Heart Rate Monitor

• Product Description

The Display Screen Housing Fixing Shaft refers to the hinge structure connecting the screen housing to the main unit base.

It is the core mechanical component enabling the EDAN F2 fetal monitor display to fold and adjust its angle—the dual-axis damping hinge. If this component is damaged (e.g., loose screws, damping failure), the screen may not be able to maintain its angle or fold.

The component has a large oval-shaped cutout in the middle, dividing the hinge into two independent rotation axes.

A long strip of metal has multiple evenly distributed circular holes, which are used to secure the hinge to the display back cover and the main unit body respectively using screws.

• Product Specifications

• Frequently Asked Questions and Maintenance

If you encounter problems related to this component during use (such as a loose screen or inability to fix the angle), it is usually due to damping wear or loose fixing screws.

Recommendation:

1. Do not force it open or move it beyond its mechanical limit angle to avoid damaging the internal wiring.

2. Contact after-sales service. Due to the involvement of delicate internal wiring, self-disassembly may cause screen malfunction.

• Function

1. Connectivity:

It serves as the physical connection between the display module and the main unit base.

2. Folding Capability:

The EDAN F2's screen is foldable for easy storage. This hinge allows the screen to fold backward, making the device resemble a book when closed, facilitating portability and storage.

3. Angle Adjustment:

Doctors or nurses can adjust the screen to the most comfortable viewing angle as needed (e.g., unfolded flat, upright, or semi-folded).

• FAQ:

   1. Are there any special requirements for the compatibility of ventilator equipment accessories?

    Yes. We test the sealing and breathability of the accessories to ensure they comply with the operational standards of the ventilator equipment, thereby safeguarding patient safety.

   2. Will color variations in accessories affect the appearance of the device?

     Yes, but the deviations are minimal and do not impact functionality. If you have strict aesthetic requirements, please inform us in advance, and we will strive to match the colors accordingly.

   3. If the accessory color deviates significantly, can it be replaced?

     Yes. If the color deviation exceeds your acceptable range, we will replace the accessory free of charge to ensure consistent appearance.

   4. Can we provide a comparison video of accessory and device compatibility?

      Yes. We can shoot a comparison video to visually demonstrate the compatibility and performance differences between our accessories and original components.

   5. How long does it take to provide comparison videos?

     Standard models will be delivered within 2–3 working days; customized or rare models will be delivered within 5–7 working days.
