EDAN F2 Fetal Monitor Encoder Button Panel Connection Cable 01.13.1161.11 Repair Parts

• Product Description

It is a short, flat ribbon cable with white, foolproof connectors at both ends. Internally, it contains multi-colored wires (red, white, black, etc.) for signal and power transmission.

This cable is specifically designed to connect the front panel operating area of ​​the monitor to the main control board. Its core function is to accurately transmit user commands input via the encoder knob and soft keys to the main control system.

When your F2 monitor experiences issues such as unresponsive knobs, malfunctioning buttons, or an unresponsive panel, replacing this cable can usually effectively resolve the problem. It is an essential emergency spare part for hospital equipment departments and third-party repair shops.

• Product Specifications

• Usage Guide & Tips

1. Fault Diagnosis:
If the monitor screen is normal but the knob rotation does not move the cursor or buttons are unresponsive, check this cable first.

2. Disassembly Note:
Always disconnect the power and remove the battery before replacement to prevent static electricity or short circuits from damaging the motherboard.

3. Interface Confirmation:
Confirm the plug orientation during installation (usually has a fool-proof design). Do not force the plug to avoid damaging the pins.

4. Applicability:
Only for the EDAN F2 series monitor. Please verify that the old part number is 01.13.1161.11.

• Function

1. Knob Signal Transmission:

Transmits signals generated when the user rotates the "Encoder Knob," used to move the cursor or adjust parameters in the menu.

2. Button Signal Transmission:

Transmits on/off signals when the user presses soft buttons on the front panel (such as Confirm, Exit, etc.).

3. Power Supply:

May provide power to the backlight on the main panel or the LED indicator lights inside the knob.
