Complete Casing Assembly For EDAN F2 Fetal Monitor With TOCO US Interfaces And Built-in Speaker

Complete Casing Assembly For EDAN F2 Fetal Monitor With TOCO US Interfaces And Built-in Speaker

Product Description

This product is a complete housing assembly designed specifically for the F2 series fetal monitors, integrating key functional interfaces and an audio alarm system. The compact and lightweight housing features a dedicated TOCO (Tooth Oxygen Control Unit) and ultrasound transducer connection port on the front panel for secure and reliable connection to external monitoring probes. A built-in high-quality speaker clearly outputs fetal heart rate sounds and system alarms, ensuring clear voice prompts in clinical settings. The housing also includes a convenient probe holder for organized transducer storage when not in use. Its robust construction and ergonomic design make it suitable for hospital and outpatient environments, protecting internal components while facilitating transportation and routine clinical use.

Specifications

Main functions

1. The monitor's internal mainboard, power supply, and wiring are fully enclosed for protection, providing dust, splash, and impact resistance.

2. It integrates a TOCO contraction probe interface and a US ultrasound probe interface, ensuring stable probe connection and signal transmission.

3. A built-in speaker mounting position ensures clear, unmuffled, and distortion-free transmission of fetal heart sounds and alarm tones.

4. Internal modules and wiring are secured to prevent loosening or poor contact during device movement.

5. The buttons, screen, interfaces, and speaker holes are uniformly and systematically positioned for ease of operation and safe use.

Usage Precautions

• Before disassembling or assembling, the device power must be turned off, the power cord unplugged, and the battery removed to prevent short circuits or electric shock.
• During disassembly and assembly, use gentle force; do not pry forcefully to avoid breaking clips or deforming the casing.
• When installing, carefully arrange the internal cables; do not squeeze or bend the screen cable, sensor cable, or speaker cable.
• Align the interfaces and speaker positions to avoid misalignment that may cause poor contact or muffled sound.
• For daily cleaning, wipe with 70% medical alcohol; do not use strong corrosive substances.
• Avoid heavy objects pressing on or forcefully impacting the casing to prevent interface deformation or casing cracking.
• Store spare casings in a dry, ventilated, and dark environment to prevent plastic aging, discoloration, and deformation.
