Introduction
At its core, the iPM 10 is a plug‑and‑play modular monitor. The main unit provides the most frequently used vital parameters – ECG, NIBP, SpO₂, temperature, and respiration and thanks to the modular architecture, advanced functions such as IBP, cardiac output, CO₂, and multi‑gas monitoring can be added flexibly as clinical needs change. Modules can be shared between beds, offering an efficient solution for departments with varying acuity levels.
The monitor is built around a custom‑designed integrated ASIC chip, which replaces the traditional circuit board architecture. This gives the iPM series greater stability and reliability compared to conventional monitors.
Parameter
| Parameter | Specifications |
| ECG |
3/5lead (I, II, III, aVR, aVL, aVF, V); gain ×0.125–×4 + Auto; sweep 6.25/12.5/25/50 mm/s; bandwidth: Diag 0.05–150Hz, Monitor 0.5–40Hz, Surgery 1–20Hz, ST 0.05–40Hz; HR adult 15–300 bpm, ped/neo 15–350 bpm; ST analysis –2.0 to +2.0 mV (adult only); arrhythmia ≥20 types incl. AF; accuracy ±1 bpm or ±1% (greater); defib protection 5000V, recovery ≤10s |
| Respiration |
Impedance method; adult 0–120 rpm, ped/neo 0–150 rpm; resolution 1 rpm; accuracy ±2 rpm or ±2% (greater) for 7–150 rpm |
| SpO₂ |
Range 0–100%; resolution 1%; refresh 1s; |
| NIBP |
Oscillometric; modes: Manual, Auto, Continuous, Sequence; systolic 25–290 mmHg, diastolic 10–250 mmHg, mean 15–260 mmHg; accuracy ±3 mmHg or ±2% (greater); adult/ped/neo modes |
| Temperature |
Dual channels (T1, T2) with TD; accuracy ±0.1°C typical; |
Mounting options
-
The monitor can be placed on a bedside table, mounted on a mobile stand, or attached to a wall bracket. The integrated quick‑release mount allows it to be conveniently and quickly mounted for bedside monitoring and dismounted for transportation
Connecting power
-
Connect the power cord to the monitor and plug it into a mains outlet (100–240 V AC, 50/60 Hz).
-
The monitor will power on automatically or via the power button.
-
If using battery power, ensure the internal rechargeable lithium battery is installed and charged
Please note:
Verify both AC power supply and remaining battery charge prior to patient monitoring. Relying solely on battery power is acceptable only for short‑term use; connect mains power for long‑term operationsMindray.
Match correct accessory sizes for each patient. For NIBP measurements, select a proper cuff size. Wrong cuff dimensions will produce unreliable blood‑pressure results. Avoid placing the cuff on limbs with IV lines or arterial cathetersMindray.
Keep signal sensors away from strong ambient light. Patient motion, nail polish and poor peripheral circulation may interfere with SpO₂ measurement outputsMindray.
Shut down the monitor and disconnect all power connections before cleaning. Do not spill liquid onto the device or submerge any component.
