Polyester Filter Bag Dust Filter Bags Polyester Needle Felt Filter For Cement Dust
Polyester filter bag Polyester needle felt filter for cement dust
Product description
Polyester normal temperature needle-punched felt is a thin fiber cloth with interlaced fibers arranged in a non-woven needle-punched process and uniform gap distribution. The surface of the needle-punched felt produced by polyester staple fiber and polyester twisted yarn is hot rolled, singed or coated After post-treatment, the surface is smooth and not easy to be blocked by dust. The filter material has a large porosity, good air permeability, a wide range of uses, and strong chemical stability. It can not only filter room temperature gases, but also filter acids and alkalis. It can filter water and oil. It is an ideal filter material for normal temperature working conditions, liquid-solid separation and other fields.
| Material | Polyester | |
| Weight(g/m2) | 500 | |
|
Tensile Strength (N/5×20cm) |
Warp | ≥1100 |
| Weft | ≥1300 | |
| Tensile elongation(%) | Warp | <35 |
| Weft | <40 | |
|
Temperature(℃)
|
Continue | 130 |
| Instant | 150 | |
| Thickness(mm) | 1.8 | |
| Air permeability(L/m²/s) | 200~350 | |
| Finishing treatment | Singeing,Calendering | |
|
Material
|
Polyester Filter Cloth
|
||||||||
|
Base Fabric
|
Normal
|
High Strength
|
|||||||
|
Weight (g/m2)
|
450
|
500
|
550
|
600
|
450
|
500
|
550
|
600
|
|
|
Thickness (mm)
|
1.6
|
1.8
|
2
|
2.2
|
1.55
|
1.75
|
1.95
|
2.15
|
|
|
Air Permeability (L/m2/S)
|
330
|
300
|
250
|
220
|
325
|
285
|
275
|
230
|
|
|
Break Elongation (N/5x20cm)
|
Warp
|
>750
|
>750
|
>800
|
>800
|
>1000
|
>1100
|
>1100
|
>1150
|
|
Weft
|
>1150
|
>1200
|
>1300
|
>1400
|
>1300
|
>1400
|
>1500
|
>1500
|
|
|
Liner Strinkage (%)
|
Warp
|
<35
|
<35
|
<35
|
<35
|
<25
|
<25
|
<25
|
<25
|
|
Weft
|
<55
|
<55
|
<55
|
<55
|
<45
|
<45
|
<45
|
<45
|
|
|
Break Strength (Mpa/min)
|
2.2
|
2.25
|
2.35
|
2.45
|
2.4
|
2.45
|
2.5
|
2.6
|
|
|
Operating Temperature (℃)
|
≤130
|
≤130
|
≤130
|
≤130
|
≤130
|
≤130
|
≤130
|
≤130
|
|
|
Instant Temperature (℃)
|
150
|
150
|
150
|
150
|
150
|
150
|
150
|
150
|
|
|
Resistance to Acid
|
Good
|
||||||||
|
Resistance to Alkali
|
Fair
|
||||||||
|
Resistance to Abrasion
|
Excellent
|
||||||||
|
Resistance to Hydrolysis
|
Fair
|
||||||||
|
Mechanical Finish
|
Singed, Glazed, Heat-Seting
|
||||||||
Related products
Q: How to choose the right filter bags?
A: There are many characteristics and parameters for different filter bags, we would love to provide you the filter products and solutions. The following parameters are what we have to know when helping to choose the right bags: 1) Working temperature ( Continuous / Peak). 2)Measurement of filter bags. 3) Gas’ chemical properties. 4) Working pressure. 5) Emission concentration.
A: We have our own factory.
Q: Do you support OEM made?
A: OEM is warmly welcomed, we can arrange your own color or label, print your OEM package, and make your own shape according to your drawing.
A: Yes, we could offer the sample for free charge, you only have to pay the cost of freight.
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q: How's the after-sale service?
A: We’ll take photos for your check before loading container and confirm all of documents within 48 hours after shipment. For any other supplier order,you just ask them to deliver us for combine container,we’ll do this favor to arrange everything very well.
Q: What is your terms of payment?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Please feel free to contact us if you have any questions.
