Thick 2.11mm To 60mm Carbon Steel Seamless Pipe Api 5l Grade B Seamless Pipe
Price:
NEGOCIATION
MOQ:
1TON
Delivery Time:
5DAYS
Brand:
XF
Product Description
Carbon steel pipe ,API 5L Pipe, Carbon Steel seamless pipe ,black steel pipe,seamless galvanized steel pipe
-
Types of seamless pipe
Large diameter pipe
Precision pipe
Thin wall pipe
Thickness wall pipe![Caliber of seamless steel pipe]()
- Sizes of seamless pipe
Out diameter: 1/2 inch - 36 inch (21.3mm-914.4mm)
Thickness: 2.11mm-60mm ( SCH10, SCH20, SCH40, SCH80, STD, SCH120, SCH160, XXS)
Materials of seamless pipe
ASTM
ASTM A53 GR.B / ASTM A106 GR.B / ASTM A179 / ASTM A192 / ASTM A210 / ASTM A210 / ASTM A213 / ASTM A333 GR.6
API
API 5L GR.B / X42 / X46 / X52 / X56 / X60 / X65 / X70
DIN/EN
DN 17175 ST35, ST52 /EN10216-2 / DIN 2391 ST35, ST52 /EN10305-1 / DIN 1629/EN10216-1
Process of Seamless Pipe![]()
Specification:
| Available Dimension Range | |||||||||||||
| OD(mm/inch) | Wall thickness(SCH) | ||||||||||||
| 10 | 20 | 30 | STD | 40 | 60 | XS | 80 | 100 | 120 | 140 | 160 | XXS | |
| 21.3 (1/2'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
| 26.7 (3/4'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
| 33.4 (1'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
| 42.2 (1 1/4'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
| 48.3 (1 1/2'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
| 60.3 (2'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
| 73 (2 1/2'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
| 88.9 (3'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
| 101.6 (3 1/2'') | √ | √ | √ | √ | √ | √ | |||||||
| 114.3 (4'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | ||||
| 141.3 (5'') | √ | √ | √ | √ | √ | √ | √ | ||||||
| 168.3 (6'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
| 219.1 (8'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
| 273 (10'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
| 323.8 (12'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ |
| 355.6 (14'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
| 406.4 (16'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
| 457 (18'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
| 508 (20'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
| 559 (22'') | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | ||
| 610 (24'') | √ | √ | √ | √ | √ | √ | √ | √ | |||||
| 660 (26'') | √ | √ | √ | ||||||||||
| 711 (28'') | √ | √ | √ | √ | √ | ||||||||
| 762 (30'') | √ | √ | √ | √ | √ | ||||||||
| 813 (32'') | √ | √ | √ | √ | √ | √ | |||||||
| 864 (34'') | √ | √ | √ | √ | √ | √ | |||||||
| 914 (36'') | √ | √ | √ | √ | √ | √ | |||||||
Chemical Analysis
| API 5L-PSL 2 Chemical Requirements | |||||||||
| Grade | Composition, % | ||||||||
| C | Si | Mn | P | S | V | Nb | Ti | Other | |
| BN | 0.24 | 0.4 | 1.2 | 0.025 | 0.015 | c | c | 0.04 | e,l |
| X42N | 0.24 | 0.4 | 1.2 | 0.025 | 0.015 | 0.06 | 0.06 | 0.04 | e,l |
| X46N | 0.24 | 0.4 | 1.4 | 0.025 | 0.015 | 0.07 | 0.07 | 0.04 | d,e,l |
| X52N | 0.24 | 0.45 | 1.4 | 0.025 | 0.015 | 0.1 | 0.1 | 0.04 | d,e,l |
| X56N | 0.24 | 0.45 | 1.4 | 0.025 | 0.015 | 0.1 | 0.1 | 0.04 | d,e,l |
| X60N | 0.24 | 0.45 | 1.4 | 0.025 | 0.015 | 0.1 | 0.1 | 0.04 | g,h,l |
| BQ | 0.18 | 0.45 | 1.4 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l |
| X42Q | 0.18 | 0.45 | 1.4 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l |
| X46Q | 0.18 | 0.45 | 1.4 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l |
| X52Q | 0.18 | 0.45 | 1.5 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l |
| X56Q | 0.18 | 0.45 | 1.5 | 0.025 | 0.015 | 0.07 | 0.07 | 0.04 | d,e,l |
| X60Q | 0.18 | 0.45 | 1.7 | 0.025 | 0.015 | g | g | g | h,l |
| X65Q | 0.18 | 0.45 | 1.7 | 0.025 | 0.015 | g | g | g | h,l |
| X70Q | 0.18 | 0.45 | 1.8 | 0.025 | 0.015 | g | g | g | h,l |
Mechanial Properties
| API 5L-PSL 2 Mechanical Properties | ||||||
| Grade | Yield Strength Mpa | Tensile Strength Mpa | Raito | Elongation | ||
| min | max | min | max | max | min | |
| BN | 245 | 450 | 415 | 655 | 0.93 | f |
| BQ | ||||||
| X42N | 290 | 495 | 415 | 655 | 0.93 | f |
| X42Q | ||||||
| X46N | 320 | 525 | 435 | 655 | 0.93 | f |
| X46Q | ||||||
| X52N | 360 | 530 | 460 | 760 | 0.93 | f |
| X52Q | ||||||
| X56N | 390 | 545 | 490 | 760 | 0.93 | f |
| X56Q | ||||||
| X60N | 415 | 565 | 520 | 760 | 0.93 | f |
| X60Q | ||||||
| X65Q | 450 | 600 | 535 | 760 | 0.93 | f |
| X70Q | 485 | 635 | 570 | 760 | 0.93 | f |
