304 321 316 ANSI B16.9 ButtWeld ELBOW Seamless SCH10 SCH20 SCH100 SCH120 XXS
ANSI B 16.9 BUTT WELDED & seamless SCH10 SCH20 SCH40 SCH80 SCH100 SCH120 SCH160 XXS ELOBW
1. Material: 304, 304L, 321, 316, 316L, etc.
2. Standard: ASME, MSS, HG, DIN, JIS, GB
3. Type: 90 degree Long Radius, 90 degree Short Radius, 45 degree Long Radius, 180 degree Return Band
We offer Sanitary Fittings, Stainless Steel Sanitary Fittings, and Stainless Steel Tube Fittings that are manufactured using optimum quality stainless steel. Our wide array of sanitary stainless steel tee is known among the customer’s due to its tensile strength. These Steel Tube Fittings in various grades and finishes as per the needs.
Specification of Stainless Steel Butt Welded Elbow:
| Specification | Type | Data |
| Size | 90 degree Long/Short Radius 45 degree Long Radius |
Seamless 1/2”-20”(DN15-DN500) Welded 1/2”-48” (DN15-DN1200) |
| 180 degree Return Band | Seamless 1/2”-4”(DN15-DN100) | |
| Wall Thickness | 90 degree Long/Short Radius 45 degree Long Radius |
SCH5S-SCH160 |
| 180 degree Return Band | SCH5S-SCH80S | |
| Material | 304, 304L, 321, 316, 316L, etc. | |
| Standard | GB/T12459, GB/T13401, SH3408, SH3409, HG/T21635 | |
| HG/T21631, ASME B16.9, MSS SP-43, DIN 2605, JIS B2313 | ||
Types of Stainless Steel Butt Welded Elbow :
Technical Parameter:
| Butt-welding Elbows ANSI B16.9 | ||||
| Nominal Diameter | Outside
Diameter/mm |
Center to End/mm | ||
|
45 degree Elbow
|
90 degree Elbow | |||
| DN | OD | Long Radius | Long Radius | Short Radius |
| 1/2 | 21.3 | 15.7 | 38.1 | - |
| 3/4 | 26.7 | 19.1 | 38.1 | - |
| 1 | 33.4 | 22.4 | 38.1 | 25.4 |
| 1 1/4 | 42.2 | 25.4 | 47.8 | 31.8 |
| 1 1/2 | 48.3 | 28.4 | 57.2 | 38.1 |
| 2 | 60.3 | 35.1 | 76.2 | 50.8 |
| 2 1/2 | 73 | 44.5 | 95.3 | 63.5 |
| 3 | 88.9 | 50.8 | 114.3 | 76.2 |
| 3 1/2 | 101.6 | 57.2 | 133.4 | 88.9 |
| 4 | 114.3 | 63.5 | 152.4 | 101.6 |
| 5 | 141.3 | 79.2 | 190.5 | 127 |
| 5 | 168.3 | 95.3 | 228.6 | 152.4 |
| 8 | 219.1 | 127 | 304.8 | 203.2 |
| 10 | 273.1 | 158.8 | 381 | 254 |
| 12 | 323.9 | 190.5 | 457.2 | 304.8 |
| 14 | 355.6 | 222.3 | 533.4 | 355.6 |
| 16 | 406.4 | 254 | 609.6 | 406.4 |
| 18 | 457.2 | 285.8 | 685.8 | 457.2 |
| 20 | 508 | 317.5 | 762 | 508 |
| 22 | 558.8 | 342.9 | 838.2 | 558.8 |
| 24 | 609.6 | 381 | 914.4 | 609.6 |
Specification of Stainless Steel Butt Welded Elbow:
| Specification | Type | Data |
| Size | 90 degree Long/Short Radius 45 degree Long Radius |
Seamless 1/2”-20”(DN15-DN500) Welded 1/2”-48” (DN15-DN1200) |
| 180 degree Return Band | Seamless 1/2”-4”(DN15-DN100) | |
| Wall Thickness | 90 degree Long/Short Radius 45 degree Long Radius |
SCH5S-SCH160 |
| 180 degree Return Band | SCH5S-SCH80S | |
| Material | 304, 304L, 321, 316, 316L, etc. | |
| Standard | GB/T12459, GB/T13401, SH3408, SH3409, HG/T21635 | |
| HG/T21631, ASME B16.9, MSS SP-43, DIN 2605, JIS B2313 | ||
