| Parts for your 306E MINI HYD EXCAVATOR: | |||||
| Pos. | Part No | Qty | Parts name | Comments | |
| 1 | 6R-7943 M | [2] | SCREW (M5X0.8X15-MM) | ||
| 2 | 180-6213 | [1] | RING-RETAINING | ||
| 3 | 258-0139 | [1] | SEAL-SHAFT | ||
| 4 | 2M-9780 | [3] | SEAL-O-RING | ||
| 5 | 386-6610 | [1] | SPRING | ||
| 6 | 146-3493 | [1] | PIN | ||
| 7 | 8T-2503 M | [4] | BOLT-SOCKET HEAD (M14X2X35-MM) | ||
| 8 | 168-3504 | [2] | SEAL | ||
| 9 | 258-0135 | [2] | PLUG | ||
| 10 | 190-6507 | [1] | RING-STOP | ||
| 11 | 9W-2110 | [1] | CUP-TAPERED ROLLER | ||
| 12 | 8J-0412 | [1] | CUP-BEARING | ||
| 13 | 192-7470 | [1] | SEAL-O-RING | ||
| 14 | 197-2850 | [1] | SHAFT | ||
| 15 | 168-2203 | [1] | SHIM-SHAFT (3-MM THK) | ||
| 16 | 386-6612 | [1] | BEARING-CRADLE | ||
| 17 | 386-6611 | [1] | BEARING-CRADLE | ||
| 18 | 398-7457 Y | [1] | VALVE GP-PUMP CONTROL (FLOW COMPENSATOR)(FLOW COMPENSATOR) | ||
| 19 | 379-5187 | [1] | SPRING | ||
| 20 | 333-7840 | [1] | STOP | ||
| 21 | 398-7458 | [1] | VALVE GP-PUMP CONTROL (TORQUE LIMITING SPOOL)(PISTON) | ||
| 22 | 378-2842 | [1] | ROTATING GP-PUMP | ||
| 23 | 378-2843 | [1] | PLATE-PORT | ||
| 24 | 9S-8006 | [3] | PLUG (7/8-14-THD) | ||
| 25 | 3P-1210 | [1] | CONE-BEARING | ||
| 26 | 9W-2109 | [1] | CONE-BEARING | ||
| M | METRIC PART | ||||
| Y | SEPARATE ILLUSTRATION | ||||
