Aumation 65K TFT HMI Control Panel 32Bit Industrial Grade CPU

Aumation Human Machine Interface Touch Screen 4.3'' TFT Modbus Control Panel

Specification:

Model : TK6043FH

Support English, Russian, Spanish, French, Polish, Turkey, Arabia, Chinese etc almost all language and word fonts.

Support Modbus rtu protocol, programming port protocol, fre port protocol.

Features:

1. IP65 Panel protection grade, 65K TFT
   Brand new high-brightness,high-contrast display LCD, providing colorful operation interface.

2. Onboard 408MHz high performance 32Bit industrial grade CPU
   has fast running speed,high data processing efficiency and strong anti-interference ability.

3. Thin and light embedded

   Can be easily installed in various complex industrial application environments.

4. Data security upgrade
   This series of HMl supports password man-agement functions. Users can set passwords for specific registers, buttons,and screens, and add permissions to ensure data security

5.

   Conformal coating protection for motherboard
   In various harsh industrial environments, it is more effective against shock, moisture,high and low temperature, and chemical corrosion.



   Model	TK6043FH
   Cutout size	120*94mm
   Display	4.3" TFT
   Resolution	480*272
   Brightness	400cd/m²
   Backlight time	60,000 hours
   Display color	65536 colors
   ROM	NOR Flash 8MB
   RAM	64MB
   CPU	32bit CPU 408MHz
   Download port	Type-C
   COM port	1 RS232, 1 RS485
   Protocol	Support MODBUS, free port and common PLC communication Protocol
   Protection Class	IP65 (front panel)
