7 Inch Touch Screen HMI PLC All In One RAM 64MB 800X480 Resolution

Price Negotiable

Price: Negotiable

MOQ: 1 unit

Delivery Time: 5-8 work days

Brand: Coolmay

Product Description

7 inch touch screen hmi plc all in one integrated controllers

Specification

Display	Dimension	20014636mm
	Cutout size	192*138mm
	Type	7"TFT
	Feature	60K-color resistive touch screen, supports portrait display
Memory	RAM	64MB
	ROM	NOR Flash 16MB
	CPU	32bit CPU 408MHz
I/O	DI/DO	Max 24DI/20DO (max 16MR)
	DI/DO level	Input: Passive NPN, public terminal isolated Transistor output: Low level NPN, COM connect to negative; Relay output: Normally open dry contact
	DO type and load	Relay MR/MOS tube, MOS tube: 2A/point, 4A/4 point COM, 5A/12 point COM; MR: 2A/point, 5A/12 point COM.
	Analog I/O (optional)	Max 12AI/8AO
	AI type (optional)	Thermocouple E/E_/K/K_/S/S_/T/T_/J/J_ / PT100/ PT1000/ NTC10K/ NTC50K/ NTC100K/ 0~10V/ 0~5V/ 0~20mA/ 4~20mA/ -5V~5V/ -10V~10V / mixed
	AO type (optional)	0~10V /0~5V/ 0~20mA/ 4~20mA/ mixed/ -5~5V/ -10~10V (2AO for 1 minus voltage)
High-speed function	High-speed counting	Single phase 6 channel 60KHz, or 2 AB 60KHz + 1 AB 10KHz, or 2 ABZ 60KHz + 1 AB phase 10 KHz
High-speed function	High-speed pulse	8 channels, Y0-Y3 is 100KHz, Y4-Y7 is 10KHz. High-speed counting + high-speed pulse < 480KHz
Connection	HMI	Type-C HMI download port (can download PLC program through the USB penetrating function), RS232 port
	HMI	1 RS485 (changed from default RS232)
	PLC	1 TYPE-C, 1 RS232 (program port)
		1 RS485 or 2 RS485 COM ports (RS485 port on HMI and RS232 on PLC will be unavailable)
		CAN (2.0A/B) port, Ethernet port, WIFI (will occupy default RS232 port)
Software	HMI	Coolmay mView HMI Programming Software
Software	PLC	Compatible with Mitsubishi GX Developer 8.86 and WORKS 2
