Tri Axle Freezer Box Truck
HOWO 8x4 Tri Axle 40 Tons Reefer Truck Refrigerator Box Van Truck
Refrigerated truck refers to a closed van transport vehicle used to maintain the temperature of frozen or preserved goods.
A refrigerated truck is a special refrigerated transport vehicle equipped with a refrigeration unit equipped with a refrigeration unit and a polyurethane insulation compartment. The refrigerated vehicle can be based on the manufacturer and the chassis. Carrying capacity, compartment type to classify.
Refrigerated trucks are often used to transport frozen foods (freezer trucks), dairy products (dairy trucks), vegetables and fruits (fresh goods trucks), vaccine drugs (vaccine trucks), etc.
| Model | HOWO 8X4 Refrigerated TRUCK | ||||||||||||||||||||||||||||||||||||||||||||
| Gross weight kg | 16000 | ||||||||||||||||||||||||||||||||||||||||||||
| Curb weight ( kg) | 6850 | ||||||||||||||||||||||||||||||||||||||||||||
|
Engine
|
Make: SINOTRUK Diesel: 4-stroke direct injection diesel engine Model: WD615.62 266HP EURO 2 emission standard, in-line with water cooling, turbo-charging and inter-cooler Bore x Stoke: 126mm x 130mm Maximum output: 266HP at 2200rmp Displacement: 9.726L Fuel: Diesel |
||||||||||||||||||||||||||||||||||||||||||||
| Cab |
HW76, extended Cab, single berth, up/down and front/back adjustable steering wheel, new European style whole heating and ventilating system, with electronic controlled model, with four points suspension & absorber and stabilizer equipment, all the truck with the double-locking safety belts and outside sun visor. Right Hand Drive |
||||||||||||||||||||||||||||||||||||||||||||
| Transmission |
HW19710CL, SINOTRUK 10 forward & 2 reverse manual gearbox
|
||||||||||||||||||||||||||||||||||||||||||||
| Steering Gear | ZF8198, German ZF hydraulic steering with power assistance | ||||||||||||||||||||||||||||||||||||||||||||
|
Clutch |
Single plate φ430 diaphragm spring clutch | ||||||||||||||||||||||||||||||||||||||||||||
| Number of axle | 4 | ||||||||||||||||||||||||||||||||||||||||||||
|
Front axle |
HF7 STEYR/HOWO drum brake front axle, axle loading capacity is 7000kg | ||||||||||||||||||||||||||||||||||||||||||||
|
Driving axle |
ST16 Rated loading capacity: 16T, Ratio: 4.42, 4.80/5.73 Double reduction, casting axle housing, drum brake |
||||||||||||||||||||||||||||||||||||||||||||
| Front/Rear track(mm) | 2022/1830 | ||||||||||||||||||||||||||||||||||||||||||||
| Overhang front/rear(mm) | 1500/1890 | ||||||||||||||||||||||||||||||||||||||||||||
| Wheel base (mm) | 4600+1350 | ||||||||||||||||||||||||||||||||||||||||||||
| Tires | 295/80R22.5, 10+1(spare tire) | ||||||||||||||||||||||||||||||||||||||||||||
| Approach/departure angle | 16/23(°) | ||||||||||||||||||||||||||||||||||||||||||||
| Maximum speed(km/h) | 90 | ||||||||||||||||||||||||||||||||||||||||||||
| Van dimension | 5.4x2.3x2.3m | ||||||||||||||||||||||||||||||||||||||||||||
| Fuel Tank | 400L | ||||||||||||||||||||||||||||||||||||||||||||
| Suspension |
Steer Axle: Parabolic springs with shock absorbers and stabilizer Drive Axle: Parabolic springs with divided balance shaft and stabilizer |
||||||||||||||||||||||||||||||||||||||||||||
| Electrical System |
Voltage: 24V Batteries: 2x12V 165Ah Starter: 24V, 5.5KW Alternator: 28V/80A |
||||||||||||||||||||||||||||||||||||||||||||
| Braking System |
Service brake: Dual-circuit air brake Parking brake: Spring brakes on rear axle Auxiliary brake: Exhaust valve braking(EVB) |
||||||||||||||||||||||||||||||||||||||||||||
| Color |
Standard: red, yellow, green, white, blue, black Optional: others you liked |
||||||||||||||||||||||||||||||||||||||||||||
| Overall Dimension(L X W X H mm) | 8000x2500x3000 | ||||||||||||||||||||||||||||||||||||||||||||
| Others | Temperature: 4 to -20 | ||||||||||||||||||||||||||||||||||||||||||||
| Options | ABS, AC,Electrical tilting cab, MTCO tachographs | ||||||||||||||||||||||||||||||||||||||||||||
