BA Surface Nickel Alloy Pipe Hot Forging Abrasion Resistant Steel K500
Prime Quality Alloy Steel Sheet Plate Monel 400 405 K500 600 Nickel Alloy Tube Pipe Plate Bar
Product Description:
Monel 400 is a kind of corrosion resistant alloy with the largest dosage, the widest application and excellent comprehensive performance. This alloy has excellent corrosion resistance in hydrofluoric acid and fluorogas medium, and also has excellent corrosion resistance to hot concentrated lye. It is also resistant to corrosion of neutral solution, water, seawater, atmosphere and organic compounds. An important characteristic of this alloy is that it generally does not produce stress corrosion crack and has good cutting performance.
Chemical Composition (%) of Nickel Copper Alloy Sheet:
| Item | Ni% | Cu% | Al% | Ti% | Fe% | Mn% | S% | C% | Si% |
| Monel 400 | ≥63 | 28-34 | 2.3-3.15 | 0.35-0.85 | Max2.5 | Max2 | Max0.024 | Max0.3 | Max0.5 |
| Monel k500 | ≥63 | 27-33 | 2.3-3.15 | 0.35-0.85 | Max2 | Max1.5 | Max0.01 | Max0.25 | Max0.5 |
Mechanical Properties of Monel400 Sheet:
| Tensile strength | yield strength | elongation |
| σb≥450Mpa | σb≥170Mpa | δ≥30% |
Standard referance:
| Monel 400 | Bar/Rod | Forging | Pipe | Sheet/Strip | Welding Wire |
| Standard | ASTM B865 | AMS4676 | ASTM B865 | ASTM B564 | ERNiCu-7 |
Product details:
| Product Name | Monel 400 405 k500 600 Nickel Alloy Tube Pipe Palte Bar |
| Material | Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy |
| Shape |
Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square, Bar,Pipe,Sheet |
| Specification | Wire: 0.01-10mm Strip: 0.05*5.0-5.0*250mm Bar: φ4-50mm;Length 2000-5000mm Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm |
| Product Characteristics |
1.According to the preparation process can be divided into deformation superalloys, casting superalloys and powder metallurgy superalloys. 2.According to the strengthening mode, there are solid solution strengthening type, precipitation strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc.. |
| Inspection | ISO,SGS,BV and so on. |
| Application | High temperature components such as turbine blades, guide vanes, turbine disks, high pressure compressor disks,machine manufacturing and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines |
Product package:
The wear resistant steel sheet will be packed in seaworthy packing such as steel strips bundles. If you have any special requests on this, please let us know advanced. We will refer to your email kindly.
1).20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) Max length is 5.8m, max weight is 25 tons.
2).40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) Max length is11.8m, max weight is 26 tons.
3).40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)
Our Advantage:
1. Honest business with competitive price
2. Professional service on export process
3. Good payment term
4. Good reputation en every market
5. Quality assurance
6. Always a pre-production sample before mass production
7. Always final inspection before mass production
Product&Our Company Show:
Packing&Shipping:
|
|
