Bright Cold Drawn Hot Rolled Thickness 5mm 316 Stainless Steel Flat Bar
Bright Cold Drawn Hot Rolled Tickness 5mm Stainless Steel Flat Bar
Product Description:
Cold-drawn steel is made by cold-extrusion technology with precise dies to produce various types of high precision, smooth surface and different shapes of steel, such as round steel, square steel, flat steel, hexagonal steel and other shaped steel.
Cold-drawn steel products have the following advantages: the diversity of shapes and specifications by designing different shapes of moulds, cold-drawn different cross-sectional shapes, different sizes and tolerances. Angles can be set at right or rounded corners. High precision using high quality carbide moulds and professional technicians, accurate tolerances, uniform surface smoothness Advanced cold-drawing technology makes the surface of cold-drawn steel products smooth and bright material savings Cold-drawn steel is the cold extrusion of raw materials to achieve the required shape, the required specifications and tolerances, the loss of raw materials is very small, compared to the use of traditional lathe machine cutting materials lost, cold-drawn steel material savings The material savings from cold drawn steel are very significant, especially when the amount of material used is large, the material cost savings are even more significant. The savings in processing time and processing machinery, due to the accurate precision and good surface condition, cold drawn steel products can be used directly, such as spraying, sanding, bending, drilling or plating directly after the actual requirements of fine drawing, eliminating a lot of processing time and saving the cost of configuring processing machinery.
|
Length
|
2000mm/ 2440mm/ 2500mm/ 3000mm/ 6000mm/ 8000mm/ 10000mm or
any length
|
|
Width
|
20mm-500mm
|
|
Thickness
|
0.5mm-50mm
|
|
Standard
|
AISI,ASTM,DIN,JIS,GB ,JIS,SUS,EN,etc
|
|
Technique
|
Cold drawn/hot rolled/slitting
|
|
Surface Treatment
|
No.1/No.3/No.4/HL/2D/2B/BA/4B/8K
|
|
Thickness Tolerance
|
Cold drawn: ±0.02mm Hot rolled: ±0.05mm
|
|
Material
|
201J1/201J2/202/304/304L/304H/316/316L/316Ti/321/309S/310S/904L
/410/420J1/420J2/430/441/443/436/439/409/409L/1.4529(NO8926)/S32760/347H/317L/
Monel400/Hastelloy C-22/C-276/S31254(254SMO)/2205/2507/600/625/800/825 |
|
Application
|
Machine shells, cans, pressure vessels, automotive precision parts, boilers, energy (nuclear power, thermal power, fuel cells),
industrial furnaces, incinerators, heating furnaces, chemicals, petrochemicals, washing machine drums, interior panels, kitchen facilities, refrigerators, Dishwasher, pot, pot, microwave oven, display counter, water tank, hot water system equipment (solar, electric water heater), heat exchanger, automobile exhaust system, |
|
MOQ
|
1 Piece
|
|
Delivery time
|
1) 200 ton: Within 5 days after deposit 2) Customize Size:Within 10 days after deposit 3) OEM Product: Within 20 days after deposit
|
|
Capacity
|
20000 tons/month
|
Size and weight:
| Width | Thickness(mm) | |||||||||||
| 3 | 4 | 5 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 25 | 30 | |
| mm | Theoretic Weight kg/m | |||||||||||
| 10 | 0.238 | 0.32 | 0.4 | 0.48 | 0.63 | |||||||
| 15 | 0.36 | 0.48 | 0.59 | 0.71 | 0.95 | 1.19 | ||||||
| 20 | 0.476 | 0.63 | 0.79 | 0.95 | 1.27 | 1.59 | 1.9 | |||||
| 25 | 0.585 | 0.79 | 0.99 | 1.19 | 1.59 | 1.98 | 2.38 | |||||
| 30 | 0.714 | 0.95 | 1.19 | 1.43 | 1.9 | 2.38 | 2.85 | 3.33 | 3.81 | 4.758 | 5.948 | |
| 40 | 0.952 | 1.27 | 1.59 | 1.9 | 2.54 | 3.17 | 3.81 | 4.44 | 5.08 | 6.34 | 7.93 | 9.52 |
| 50 | 1.19 | 1.59 | 1.98 | 2.38 | 3.17 | 3.97 | 4.76 | 5.55 | 6.34 | 7.93 | 9.91 | 11.9 |
| 60 | 1.428 | 1.9 | 2.38 | 2.85 | 3.81 | 4.76 | 5.71 | 6.66 | 7.61 | 9.52 | 11.9 | 14.27 |
| 70 | 2.22 | 2.78 | 3.33 | 4.44 | 5.55 | 6.66 | 7.77 | 8.88 | 11.1 | 13.88 | 16.65 | |
| 80 | 3.17 | 3.81 | 5.08 | 6.34 | 7.61 | 8.88 | 10.15 | 12.69 | 15.86 | 19.03 | ||
| 90 | 3.57 | 4.28 | 5.71 | 7.14 | 8.56 | 9.99 | 11.42 | 14.27 | 17.84 | 21.41 | ||
| 100 | 3.97 | 4.76 | 6.34 | 7.93 | 9.52 | 11.1 | 12.69 | 15.86 | 19.82 | 23.79 | ||
| 110 | 5.23 | 6.98 | 8.72 | 10.47 | 12.21 | 13.96 | 17.45 | 21.81 | 26.17 | |||
| 120 | 5.71 | 7.61 | 9.52 | 11.42 | 13.32 | 15.23 | 19.03 | 23.79 | 28.56 | |||
| 130 | 6.19 | 8.25 | 10.31 | 12.37 | 14.43 | 16.49 | 20.62 | 25.77 | 30.93 | |||
| 140 | 6.66 | 8.88 | 11.1 | 13.32 | 15.54 | 17.76 | 22.2 | 27.76 | 33.31 | |||
| 150 | 7.14 | 9.52 | 11.9 | 14.27 | 16.65 | 19.03 | 23.79 | 29.74 | 35.69 | |||
| 160 | 7.61 | 12.6 | 15.23 | 17.76 | 20.3 | 25.38 | 31.72 | 38.06 | ||||
| 170 | 13.48 | 16.18 | 18.87 | 21.57 | 26.96 | 33.7 | 40.44 | |||||
| 180 | 14.27 | 17.13 | 19.98 | 22.84 | 28.55 | 35.69 | 42.82 | |||||
The production process of stainless steel flat bar as follows:
Step one: prepare stainless steel ingots(Raw materials)
Step two: hot-rolling to make flat-shape
Step three: after hot-rolling, ingot becomes flat bar(black surface)
Step four: pickling
Step five: sand-blasting(final product)
