Industrial 8 Port POE Switch With 8 10/100/1000T PoE + 1 1000Base-X Ethernet Switch
Industrial 8-Port PoE Switch with 8 10/100/1000T PoE + 1 1000Base-X Ethernet Switch
Technical Parameter
| Backboard capacity | 20G | |
| Cache | 2M | |
| MAC address | 16K | |
| Max frame | 10Kbytes | |
| Ethernet port | 8 POE 10/100/1000Mbps rj45 ports | |
| Optic interface | SFP | |
| Ethernet port (10/100/1000Mbps) | 2 | |
| Optic interface (10/100/1000Mbps) | 2 | |
| Optical type | Single fiber single mode, 9/125um (multi-mode, 50um/125unu) | |
| Optical interface | FC, SC, LC for option | |
| Transmission distance | Standard 20Km (single fiber single mode), it is customized for max. 100Km | |
| Input voltage | DC44V - 57V | |
| Working temperature | -40℃ ~ 85℃ | |
| Relative humidity | 5% ~ 90% (Non-Condensing) | |
| Shell Material | Iron | |
| Heat dissipation | Built-in passive heatsink cooling, Silent fanless design | |
| Surge protection (Ethernet) | Common mode ±4KV(10/700µS), Differential mode ±2KV(10/700µS) | |
| Surge protection (Power) | 2000A (8/20µS) | |
| POE | Standard Protocol | IEEE 802.3af/at |
| Pin Definition | V+,V+,V-,V- Corresponding to 1,2,3,6 | |
| The Output Power | IEEE802.3af:15.5W IEEE802.3at:25.5W | |
| Power consumption | Full load≤5W | |
| Mean Time Between Failure (MTBF) | 100,000 hours | |
Product Features
► 8 10/100/1000Base-TX + 1 1000Base-X
► 10/100/1000Mbps RJ45 Port Supports Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX
► Supports IEEE 802.3at PoE+ (30W per port)
► SFP, SC, FC, ST Optional
► Supports 802.3x Flow Control
► IEEE 802.3az Energy Efficient Ethernet (EEE)
► Redundant Power Inputs
► Supports Wall-mount and DIN-Rail installation
► -40°C to 80°C (-40°F to 176°F) operating temperature
