Fork Truck Clamp Attachments Turnaload Clamp 50x125x1200mm Forks
Forklift attachment turnaload with 50x125x1200mm forks
Functions & Applications
Turnaloads can hold cargo with 360 degree continuous rotation, also can be used for transferring the goods from high-grade production tray to cheaper transport pallets, saves the tray cost. Suitable for high efficiently handling and stacking operation in tobacco, paper, chemical fiber, workshop, port industries.
Features
* Proven durable T-beam arm aluminum frame construction.
* Superior arm-slide bearing for extended service life.
* Continuous 360 degree rotation, any angle position of lock function.
Options
* Fork sizes
* Various mounting classes available
* Custom opening ranges
Parameter
| Capacity@ Load Center (Kg@mm) |
Model No. | Mounting Class | Opening Range (mm) |
Fork Size (mm) |
Frame Width D(mm) |
Fork Spacing (mm) |
Vertical Center of Gravity CGV(mm) |
Weight (kg) |
Effective Thickness ET(mm) |
Horizontal Center of Gravity CGH(mm) |
| 1600@600 | TAL20D-001A | II | 580-1860 | 50x125x1000 | 1040 | 450 | 265 | 720 | 300 | 330 |
| 1600@600 | TAL20D-002A | II | 480-1720 | 45x125x1070 | 940 | 700 | 265 | 680 | 295 | 325 |
| 1600@600 | TAL20D-003A | II | 620-1900 | 50x125x1200 | 940 | 560 | 265 | 750 | 300 | 330 |
Remark:
1. Obtain the actual capacity of the forklift and attachments from the forklift manufacturer.
2. Two sets additional oil circuit required on forklift.
3. Opening range is the space between two arms tip.
4. Fork size can be customized according to user requirements.
Applicable Industries
Manufacturing Plant, Chemical fiber, Workshop, Port industries
Can be customized according to size
Customized solutions:
Carton Clamp
Block Clamp
Bale Clamp
Roll Clamp
......
all kinds of attachment
