Home Appliance Carton Clamp Forklift Attachments 535-1850mm Opening
Customized forklift clamp accessories and carton clamp of various sizes
Parameter
| Capacity@ Load Center (Kg@mm) |
Model No. | Mounting Class | Opening Range (mm) |
Arm Height A(mm) |
Arm Length B (mm) |
Frame Width D (mm) |
Vertical Center of Gravity CGV(mm) |
Weight (kg) |
Effective Thickness ET(mm) |
Horizontal Center of Gravity CGH(mm) |
| 1400@710 | CCS20D-006A | II | 560-1930 | 1220 | 1240 | 1040 | 315 | 770 | 127 | 483 |
| 1450@685 | CCS20D-007A | II | 560-1930 | 1525 | 1370 | 1040 | 380 | 824 | 127 | 485 |
| 2300@510 | CCS30D-008B | III | 535-1850 | 1525 | 1015 | 1015 | 450 | 899 | 152 | 485 |
| 2300@535 | CCS30D-009B | III | 535-1850 | 1525 | 1015 | 1015 | 450 | 906 | 152 | 485 |
Product Description
CCS20D-006A Opening Range 560-1930mm, Arm Height 1220mm, Arm Length 1240mm, Vertical Center of Gravity 315mm
CCS20D-007A Opening Range 560-1930mm, Arm Height 1525mm, Arm Length 1370mm, Vertical Center of Gravity 380mm
CCS30D-008B Opening Range 535-1850mm, Arm Height 1525mm, Arm Length 1015mm, Vertical Center of Gravity 450mm
CCS30D-009B Opening Range 535-1850mm, Arm Height 1525mm, Arm Length 1015mm, Vertical Center of Gravity 450mm
Options
* Custom opening ranges
* Various mounting classes available
Remark:
1. Obtain the actual capacity of forklift and accessories from the forklift manufacturer.
2. Two sets of additional oil circuits are required on the forklift.
3. The opening range is the space between the tips of the two arms.
4. All carton clamps are equipped with four tank pressure regulating valves
Other size available on request.
Installation & Option
Hydraulic Flow & Pressure
| Model | Min. Hydraulic Flow(L/min) |
Rec. Hydraulic Flow(L/min) |
Max. Hydraulic Flow(L/min) |
Min. Hydraulic Pressure(Bar) |
Max. Hydraulic Pressure(Bar) |
| CCS20D | 15 | 25 | 25 | 35 | 160 |
| CCS30D | 15 | 40 | 40 | 35 | 160 |
Options:
* Four position pressure regulating valve.
* Pad up and extend.
* Increase the load on the backrest.
Applicable Industries
Mechanical repair shop, manufacturing factory, catering shop, printing factory
Can be customized according to size
Customized solutions:
1. Carton Clamp
2. Block Clamp
3. Bale Clamp
4. Roll Clamp
......
all kinds of attachment
