Lightweight Mini Medical 10L Portable Oxygen Concentrator MEY-10:


Medical Mini Oxygen Concentrator Features:

Flexibly four-wheels easy to move

The easy dual flow control, makes setting the flow easy for any patients

The indicator light clearly shows the operating status of the machine

Innovative big size LCD display convenient to view the operating parameters

Optional function dual flow, easy to use for two patients at same time

US humidifier bottle with 6 PSI pressure relief valve, comfortable to inhale oxygen

The storage box at the top can conveniently place accessories such as oxygen tubes

The inside pipeline use the medical class silicone tube and nylon tube, more safe than industrial silicone tube and plastic tube, no pollution, no peculiar smell

Cooling system: copper tube and aluminum fins, compare with only aluminum or copper tube, better for heat dissipation and ensure the machine to

continuously work for 24 hours without overheat interruption

Easy Dial Flow Control Oxygen Concentrator Descriptions:

Flow Rate: 1-10L/min

Oxygen Concentration: 93%(±3%)

Power Consumption: ≤880W

Outlet pressure: 6-10PSl(0.04-0.07Mpa)

Input Frequency: 50Hz； 60 Hz

Sound level: ≤50dB

Input Voltage: AC230V±10%;AC110V±10%

Net Weight: 27KGS

Alarm Systerm Of Medical Mini Oxygen Concentrator:

1. Power failure alarm:

2. High and low pressure alarm;

3. Low oxygen purity alarm:

When oxygen purity is >82%, blue light illuminate

When oxygen purity is <82%, red light illuminate, indicating low purity

4. Low flow alarm
