Regiant 1100KG 0.8Mpa CNC Plasma Cutting Machine For Stainless Steel Aluminum
380V 25mm 12000mm/min Plasma Cutting Machine CNC
25mm CNC Plasma Flame Cutting Machine Introduction
1.Cutting head with cooling system can quickly cool surface of materials to avoid bur and reside
2.Overall stepper motor with high precision rack and pinion,to ensure the machine has small noise,smooth,precise coordinates of the mobile performance
Technology Parameters
| Model | 1325 120A Plasma cutting machine ( high configuration) |
| X,Y working area | 1300*2500mm |
| Z working area | 150mm |
| Packing dimension | 2260mm*1450mm*1850mm |
| Lathe bed | Very thick steel structure |
| Machine Power | At least 8.5 KW |
| Working voltage | 380V three phase 60hz |
| Reposition precision | 0.02mm |
| Processing precision | 0.2mm-0.5mm |
| Maximum cutting speed | 12000mm/min |
| Torch Height control mode | 150mm |
| Cutting thickness | Max 25mm carbon steel |
| Plasma power supply | China LGK 120A Plasma source (Selected:HUAYUAN or HYPERTHERM) |
| Control system | STARfire |
| Motors | Stepper motor (Selected:China or YASKAWA) |
| Rail | China or HIWIN |
| Software | Starcam |
| Weight | 1100KG |
| Plasma Air Pressure | Max.0.8Mpa |
| Working Temperature | -10°C-60°C. Relative Humidity, 0-95%. |
| LCD Display Dimension | 7 Inches |
| Rotary(Max Dia*Length) | Selected |
OXY Plasma Cutting Machine Feature:
1, CNC plasma cutting for aluminum,stainless steel use STARFIRE control system with Fastcam software for auto material saving function,large capacity storing function,convenient to read the process
2, perfect software compatibility,such as Ucancam,Type 3,Artcum,etc
Servo Motor YASKAWA Plasma Cutting Machine Application:
1. Cars, motorcycles, pressure vessels, chemical machinery, nuclear industry, general machinery, engineering machinery, steel structure, shipbuilding and other industries.silver, Titanium and other metal plate and tube.
Plasma Cutting Machine Function:
