30mm 160A CNC Plasma Cutting Machine
30mm 160A Plasma Cutting Machine CNC
30mm Plasma Flame Cutting Machine Introduction
1.High-speed stepper motor and driver,Yaxis using a dualmotor drive to make high speed operation up to 20 meters above blank line speed,with the high power spindle can greatly enhance the carving speed
2.During the plasma is cutting,if the torch of plasma break at the point,take the torch of the machine,adjust the torch,then the torch will automatically return to the break points.
Technology Parameters
| Model | 1325 160A Plasma cutting machine ( high configuration) |
| X,Y working area | 1300*2500mm |
| Z working area | 150mm |
| Packing dimension | 2260mm*1450mm*1850mm |
| Lathe bed | Very thick steel structure |
| Machine Power | At least 8.5 KW |
| Working voltage | 380V three phase 60hz |
| Reposition precision | 0.02mm |
| Processing precision | 0.2mm-0.5mm |
| Maximum cutting speed | 12000mm/min |
| Torch Height control mode | 150mm |
| Cutting thickness | Max 25mm carbon steel |
| Plasma power supply | China LGK 160A Plasma source (Selected:HUAYUAN or HYPERTHERM) |
| Control system | STARfire |
| Motors | Stepper motor (Selected:China or YASKAWA) |
| Rail | China or HIWIN |
| Software | Starcam |
| Weight | 1100KG |
| Plasma Air Pressure | Max.0.8Mpa |
| Working Temperature | -10°C-60°C. Relative Humidity, 0-95%. |
| LCD Display Dimension | 7 Inches |
| Rotary(Max Dia*Length) | Selected |
OXY Plasma Machine Feature:
1,CNC plasma cutting for aluminum,stainless steel use STARFIRE control system with Fastcam software for auto material saving function,large capacity storing function,convenient to read the process
2,perfect software compatibility,such as Ucancam,Type 3,Artcum,etc
Servo Motor Plasma Cutting Machine Application:
1. Advertising signs,logo making,decorative products,production of advertising and a variety of matel material and iron sheet,the aluminum sheet,the galvanized sheet,hundred steel plates,metal plates
HIWIN rail Plasma Cutting Machine Function:
