Starfire 160A CNC Plasma Cutting Machine 0.5- 50mm Cutting Thickness
Starfire 160A Plasma Cutting Machine CNC
China LGK 160A Plasma Flame Cutting Machine Introduction
1. we will free provide 2G processing design (USD 320) and Australia professional metal cutting software for you, in the 2G processing design have thousand beautiful graphic, after you get the machine, you can let the machine do a lot of beautiful work, while no need find the engineer to help you to design.
2. Machine structure is designed by famous mechanical professor, to add many columns for each bean. So that the machine body can bear more weight for large, thick metal sheets without deforming. But some small factories will not add these parts for saving cost, their machine is easy to deform for thick metal.
Technology Parameters
| Model | 1530 160A Plasma cutting machine ( high configuration) |
| X,Y working area | 1500*3000mm |
| Z working area | 150mm |
| Packing dimension |
2280*3950*1850 |
| Lathe bed |
3700*2600*1470 Very thick steel structure |
| Machine Power | At least 8.5 KW |
| Working voltage | 380V three phase 60hz |
| Reposition precision | 0.02mm |
| Processing precision | 0.2mm-0.5mm |
| Maximum cutting speed | 12000mm/min |
| Torch Height control mode | 150mm |
| Cutting thickness | 0.5- 50mm |
| Plasma power supply | China LGK 160A Plasma source (Selected:HUAYUAN or HYPERTHERM) |
| Control system | STARfire |
| Motors | Stepper motor (Selected:China or YASKAWA) |
| Rail | China or HIWIN |
| Software | Starcam |
| Weight | 1300KG |
| Plasma Air Pressure | Max.0.8Mpa |
| Working Temperature | -10°C-60°C. Relative Humidity, 0-95%. |
| LCD Display Dimension | 7 Inches |
| Rotary(Max Dia*Length) | Selected |
Metal Plasma Cutting Machine Feature:
1,High-speed stepper motor and driver,Yaxis using a dualmotor drive,to make high speed operation up to 20 meters above the blank line speed,with the high power spindle can greatly enhance the carving speed more.
2,Whole steel structure,high temperature tempering after welding to eliminate the stress treatment,distortion free,strong and long life
HIWIN Rail Plasma Cutting Machine Application:
1,Be widely used for panel processing, panel furniture, computer desk, office furniture, wooden speaker, wooden kitchen ware, customized wardrobe, modern cabinets, and so on
Function:
