Solar Energy 24VDC 1200W Solar Inverter Converter Customizable
Solar Energy Power Inverter 24VDC 1200W Solar Generator/ Solar Inverter Converter
>Solar Inverter Product Features
*Pure sine wave output;
*Powerful charge rate up to 140MP;
*Optional MPPT/PWM solar charge controller 50A-100A;
*With AVR function,the output voltage precision is higher;
*Automatically send signal to start generator;
*DC start and automatic self-diagnosticfunction High efficiency design and "power saving mode"to conserve energy;
*Auto restart when AC in recovering;
*Smart battery charger design for optimized battery performance;
*Selectable charging current based on applications ;
*ACinput/DC input/solar input optional priority AC start-up voltage/auto restart voltage;
*Maximum AC input current.
>Solar Inverter model
| Model | VE1012 | VE2024 | VE3048 | VE5048 | VE6048 | VE8048 | VE10048 |
| Capacity | 1000VA | 2000VA | 3000VA | 5000VA | 6000VA | 8000VA | 10000VA |
| Voltage | 12VDC | 24VDC | 48VDC | 48VDC | 48VDC | 48VDC | 48VDC |
| Rated Power | 800W | 1600W | 2400W | 4000W | 4800W | 6400W | 8000W |
| Normal Voltage | 220VAC | 220VAC | 220VAC | 220VAC | 220VAC | 220VAC | 220VAC |
| Voltage Range | 154-264VAC±3V(AC Mode), 185-264VAC±3V(UPS MODE) | ||||||
| Frequency | 50/60Hz±5% Auto Sensing | ||||||
| Power Factor | 0.85 | ||||||
| Waveform | Pure Sine Wave | ||||||
| Transfer Time | ＜8ms | ||||||
| Output Voltage | 220VAC±10% | ||||||
| Output Frequency | 50Hz/60HZ±1% | ||||||
| Bypass Mode | Yes | ||||||
| Saver Mode | Yes | ||||||
| MPPT Efficiency | ＞98% | ||||||
| Battery Type | Lead Acid Battery, Tubular Battery, Floating Battery | ||||||
| AC Charing Current | 25A | 28A | 40A | 30A | 40A | 50A | 65A |
| Battery Charging Voltage | 13.75VDC | 27VDC | 54VDC | 54VDC | 54VDC | 54VDC | 54VDC |
| Maximum PV Anay Power | 720W | 1200W | 2800W | 1200W | 2800W | 2800W | 2800W |
| MPPT (PWM) Input Voltage Range |
18-150VDC (15-33VDC) |
34-150VDC (30-66VDC) |
34-150VDC (30-66VDC) |
34-150VDC (30-66VDC) |
65-150VDC (60-150VDC) |
65-150VDC (60-150VDC) |
65-150VDC (60-150VDC) |
| MPPT(PWM)Maximum PV Display Open Circuit Voltage | 50A | 50A | 50A | 50A | 50A | 50A | 50A |
| Maximum Charging Current | Input Over Current Air Switich Protection(AC Mode) | ||||||
| Protection Function | Overload Protection, Short Circuit Protection, Low-Voltage Protection, Protection of Opposite Connection |
||||||
| LCD Indicator Status | AC Input Voltage, AC Input Frequency, PV Voltage, PV Current, Output Voltage, Output Frequency, Battery Voltage, Load Current,etc. |
||||||
| LOW Battery Protection | Audible Alarm-Continuous Beeping | ||||||
| LOW Battery Alarm | Audible Alarm-Every Seconds Beeping | ||||||
| Overload Alarm | Audible Alarm-Continuous Beeping | ||||||
| Fault | Audible Alarm-Continuous Beeping | ||||||
| Operation Temperature | 0°C~40°C | ||||||
| Storage Temperature | -15°C~45°C | ||||||
| Humidity | -10°C~90°C Non Condensing | ||||||
| Accoustic Noise | ＜45dB | ||||||
| Size(L*W*H) | 510mm*320mm*140mm | 700mm*330mm*150mm | 700mm*330mm*150mm | ||||
| Weight | 11KG | 15.5KG | 17.2KG | 22KG | 24.5KG | 28.5KG | 32KG |
>Warning
To ensure proper use of the battery please read the manual carefully before using it.
Handling
1. Do not expose to, dispose of the battery in fire.
2. Do not put the battery in a charger or equipment with wrong terminals connected.
3. Avoid shorting the battery
4. Avoid excessive physical shock or vibration.
5. Do not disassemble or deform the battery.
6. Do not immerse in water
7. Do not use the battery mixed with other different make, type, or model batteries.
8. Keep out of the reach of children.
Charge and discharge
1. Battery must be charged in appropriate charger only.
2. Never use a modified or damaged charger.
3. Do not leave battery in charger over 24 hours.
Storage
1. Store the battery in a cool, dry and well-ventilated area.
2. Disposal
Regulations vary for different countries. Dispose of in accordance with local regulations.
A1: Tell us your demand, then our sales will recommend a suitable battery for you.
Q2. Do you have any MOQ limit?
A2: Yes, we have MOQ for mass production, it depends on the different model numbers. 50-500pcs sample order is available.
Q3. Is it OK to print my logo on the product?
A3: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q4: How to solve the technical problem?
A4: 24 hours after-service consultancy just for you and to make your problem to solve easily.
Q5:. What certificate your company have?
A5: ISO 9001, ISO 14001, OHSAS 18001, CE, UL, IEC 61427 test report, Patent for gel technology and other Chinese honor.
Q6. What is your warranty time for VRLA battery ?
A6: It depends on battery capacity, depth of discharge, and battery usage.
Q7. Why battery has different capacity at different hour rate?
A7: The capacity of a battery, in Ahs, is a dynamic number that is dependent on the discharge current. For example,
Q8. Are you a battery manufacturer, and do you produce the plate by yourself ?
A8: Yes, we are a professional battery manufacture in Fujian Province, China. And we produce plates by ourselves.
Q9. How to proceed with an order?
A9. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places a deposit for formal order.
Fourthly We arrange the production.
Q10: How about the delivery time?
A10: About 7 days for stock products, around 20 days for half container products, 30 days for 20ft full container products.
