5Bag/Min SGS ISO Liquid Pouch Packing Machine For Honey Sachet 0.4mpa
Price:
Negotiable
MOQ:
1
Delivery Time:
10-20 days
Brand:
Fair Machinery
Product Description
Automatic honey liquid filling packaging machine ketchup filling packaging machine
This machine is suitable for packaging, shampoo, milk, soy sauce, chili sauce, yogurt, peanut oil, ketchup, jam, liquid or sauce. It is suitable for food, pharmaceutical, chemical, cosmetics, daily necessities, etc. Industry packaging requirements.
This machine adopts microcomputer control, Chinese and English display, digital control, easy to understand. It is easy to grasp the production and packaging situation at any time, and the machine can automatically complete the packaging process such as metering, bag making, blanking, sealing, slitting, and printing date (optional).
The temperature control system adopts a digital automatic constant temperature system, which is matched with the heat detector line, and the finished product is beautiful and has good sealing performance.
The film feeding system adopts a stepping motor to pull the film, and the contact switch senses to reduce the error of film feeding.
The filling method adopts the piston type metering pump, and the barrel can be equipped with stirring blades. The weight adjustment is convenient and simple, and the cutting is accurate. The various shapes and seals can be customized according to the customer's needs.
The filling method adopts the piston type metering pump, and the barrel can be equipped with stirring blades. The weight adjustment is convenient and simple, and the cutting is accurate. The various shapes and seals can be customized according to the customer's needs.
Technical parameters:
| Model | FSJ-240A |
| Bag length | 50-200 mm |
| Bag width | 30-100 mm |
| Power supply (VAC) | 380/220V 50/60Hz |
| Power (KW) | 2.5Kw |
| Max width of roll film | 400 |
| Packing speed | 5-40 Bag/min |
| Measuring range | 10-100,50-500,100-1000 ml |
| Air consumption | 0.65mpa |
| Dimensions (MM) | 1200x900x1600 |
| Net weight (KG) | 200 |
Bag style:
Finished product:
