CRP PCT Immunofluorescence Analyzer
Quantitative immunoassay analyzer CRP PCT cTnl Immunofluorescence Analyzer
Short detection time
The HFD Series adopts dynamic monitoring fluorescence signal technology. By continuously collectingfluorescence signal, it realizes the rapid detection of high-risk patients and gains more treatment time for them.Forexample,cTnl can be detected within 4 minutes(dry immunofluorescence chromatography takes more than 15minutes), that helps patients with myocardial infarction to get the fastest treatment.
High sensitivity
The HFD Series adopts high-sensitivity fluorescent substances,homogeneous immune reaction system anddynamic monitoring technology,which greatly improves the sensitivity.For example, the sensitivity of cTnl(Cardiactroponin l) can reach 1.6ng/mL at the 4th minute; the sensitivity of Hs-cTnl (Hypersensitive Cardiac troponin l) canreach 0.04ng/mL at the 10th minute.
High precision
The HFD Series adopts a homogeneous immune reaction system similar to biochemical or chemiluminescencereactions.Compared with the precision of traditional fluorescence chromatography of 10% to 20%, the precision ofHFD assay system could reach 5 % to10%.
Technical Parameters:
| Sample Type | serum, plasma, whole blood, urine, etc. |
| Weight | about 2Kg |
| Size | 200mm * 190mm * 180mm (L * W* H) |
| Printing | built-in thermal printer |
| Interface | RS232 serial port, Ethernet port, USB interface |
| Repeatability | CV ≤15% |
| Stability | CV ≤ 8% |
| Ambient temperature | 10 ℃ ~ 30 ℃ (Note: the operating temperature of reagent shall be subject to the instruction) |
| Relative humidity | 10% ~ 70% |
| Power supply | voltage 1A / 115VAC 0.5A / 230VAC |
| Power frequency | 47 ~ 63Hz |
