Huayang Conveying Roll Mesh Welding Machine Galvanized Wire Adjusted Transformer
Galvanized Wire Orange Roll Mesh Welding Machine
1. Product description
Galvanized wire orange roll mesh welding machine is used for making wire mesh. The raw material is galvanized wire. Galvanized wire orange roll mesh welding machine is our new type of steel wire mesh grid machine. The popular grid cell sizes are 1/2”, 1”, 2”, 12.5mm, 25mm, 50mm, 100mm, 150mm, etc. but also it is equipped with an inverter to control the speed and new type motor&reducer, with a good working performance.
2. Technical parameter
| Model | Mesh width | Minimum mesh size (inch) | Wire diameter(mm) | Welding speed (rows/min) | Roll mesh length (m) | Other available mesh size (inch) |
| R- DHW1 | 1m | 1/2x1/2 | 0.45-0.85 | 90-120 | 130 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW1 | 1m | 1/2x1/2 | 0.6-1.3 | 90-120 | 110 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW1 | 1m | 1/2x1/2 | 0.8-1.6 | 80-90 | 100 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW1 | 1m | 1x1 | 0.45-0.85 | 90-120 | 130 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW1 | 1m | 1x1 | 0.6-1.3 | 90-110 | 110 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW1 | 1m | 1x1 | 0.8-1.6 |
90-110 |
100 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW1 | 1m | 1x1 | 1.4-2.6 | 80-90 | 80 | 1x2, 2x1, 2x2, 2x4 |
3. Application area
The galvanized wire orange roll mesh welding machine is used for the production of dimensionally accurate meshwork for a wide variety of applications. Mesh welding machine for galvanized wire is used to make construction mesh, wall mesh, animal cage, mining etc.
4. Advantages
a. High speed mesh cutting system.
b. Automatic mesh turning, stacking and conveying system.
c. We can design the machine according to your wire diameter,mesh hole size and so on.
d. One time two or three mesh rolls can be produced.
e. The welding transformers can be adjusted for different wire diameters.
