Huayang PLC Dominate Roll Welding Machine , Dia 1.3mm Stainless Steel Welding Equipment
PLC Control Automatic Drive Shaft Welding Machine
1. Product description
The PLC control automatic drive shaft welding machine is used for making mesh. All of our machine we offer one year warranty, For the machine we offer video and manufal for operation, if need we can offer engineer oversea install and training, all the charge and fee also the salary of engineer will pay for by the buyer, techinical support all machine life free.
2. Technical parameter
| Model | Mesh width | Minimum mesh size (inch) | Wire diameter(mm) | Welding speed (rows/min) | Roll mesh length (m) | Other available mesh size (inch) |
| R- DHW | 1-2.5m | 1/2x1/2 | 0.6-1.3 | 90-120 | 110 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW | 1-2.5m | 1/2x1/2 | 0.8-1.6 | 80-90 | 100 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW | 1-2.5m | 1x1 | 0.6-1.3 | 90-110 | 110 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW | 1-2.5m | 1x1 | 0.8-1.6 | 90-110 | 100 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW | 1-2.5m | 1x1 | 1.4-2.6 | 80-90 | 80 | 1x2, 2x1, 2x2, 2x4 |
3. Application area
The PLC control automatic drive shaft welding machine is used to making stainless steel mesh. Common uses for welded wire mesh, or steel mesh include: fencing panels, wire partitions, wire container panels, wire baskets, animal cages, enclosure works, screens, security panels, shelving, signage, stairways/treads, fishing traps and concrete reinforcement.
4. Advantages
a. This machine adopts PLC control technique, both separate-phases welding and welding time composed of digital and integrated electric circuit, more intelligent and rational, once pressing, and separate welding.
b. Design flexibility for the plant.
c. The welding speed is fast and it is easy to learn and operate. Only two operators are enough.
d. Upgrade of other components available at any time.
e. Both longitude wire and weft wire can be fed from wire coils automatically.
