5kw Mildewproof Welded Mesh Making Machine , 6ft Width Stainless Steel Welding Equipment
Automatic Six Feet Width Weld Mesh Manufacturing Machine
1. Product description
Automatic six feet width weld mesh manufacturing machine is used for making wire mesh. This kind of machine is expert to produce mesh sheet. The finished mesh is much smoother than mechanical machines products.PLC control. Easy to set and control. It makes this machine more intelligent and reasonable.The weft wire supply is automatic. Sending wire with full automatic, Applicable to low-carbon steel wire body machine, design reasonable, less noise, easier operate, non-polar adjust the number of welding.
2. Technical parameter
| Model | Mesh width | Minimum mesh size (inch) | Wire diameter(mm) | Welding speed (rows/min) | Roll mesh length (m) | Other available mesh size (inch) |
| R- DHW | 6feet | 1/2x1/2 | 0.6-1.3 | 90-120 | 110 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW | 6feet | 1/2x1/2 | 0.8-1.6 | 80-90 | 100 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW | 6feet | 1x1 | 0.6-1.3 | 90-110 | 110 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW | 6feet | 1x1 | 0.8-1.6 |
90-110 |
100 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW | 6feet | 1x1 | 1.4-2.6 | 80-90 | 80 | 1x2, 2x1, 2x2, 2x4 |
3. Application area
The automatic six feet width weld mesh manufacturing machine is widely used for make wall mesh, concrete mesh, construction mesh, breed cage etc.
4. Advantages
a. Electrode lift system to extend electrode life.
b.Line wire loop and balance system to ensure wire mesh accuracy.
c. It has advantages of reasonable design, low noise, stable working, easier operation etc.
d. The mesh size is precise and can be set according to customers' requirements.
e. We are engaged in wire mesh welding machine for more than 20 years, providing you with the most professional knowledge and the most suitable machine.
