Low Carbon Steel Domestic CNC Spot Welding Machine Wire Dia 3mm
Automatic Low Carbon Steel CNC Spot Welding Machine
1. Product description
Automatic low carbon steel CNC spot welding machine is used for making panel mesh. It can mesh with a wire diameter direction appear on different size mesh.The greatest feature of the aircraft broke the plate wire fence films can not be used for continous production of the situation and change the wire diameter varies due to replace each of the contact pressure spring chores,minor changes in cylinder pressure knob, you can change the solder joint stress.
2. Technical parameter
| Model | HY-DHW-1500 | HY-DHW-2000 | HY-DHW-2500 | HY-DHW-2800 | HY-DHW-3300 |
| Weld width(mm) | 1500 | 2000 | 2500 | 2800 | 3300 |
| Meshi trip(mm) | Single trip 3000 and no limit on return | ||||
| Std trans.spacing | >=25mm-stepless adjustable | ||||
| Std long.spacing | >=50mm, and progressive increase by 50 | >=100mm, and increase by 100 | |||
| Std weld spots | 31 | 41 | 51 | 27 | 32 |
| Wire diameter(mm) | 3.0-6.0 | 3.0-6.0 | 3.0-6.0 | 5.0-12.0 | 5.0-12.0 |
| Weld speed(times/min | 50-70 | 40-60 | 40-60 | 40-60 | 40-60 |
| Trans material | Straight bar/rod | Straight bar | |||
| Long material | Straight bar/rod | ||||
| Control mode | PLC programming servo motor stepper | ||||
| Mesh diagonal error | <=2 | ||||
| Mesh overall error | <=2 | ||||
| Air pressure | >=0.7 | ||||
| Weld material | Cold drawn wire, galvanized wire, cold rolled ribbed steel | ||||
3. Application area
The automatic low carbon steel CNC spot welding machine can be used for production of dimensionally accurate meshwork for a wide variety of applications. Wire mesh may be used to produce shop, exhibition- and warehouse equipment as well as trays for domestic and overseas appliances.
4. Advantages
a. This line adopt special welding process ,Efficient water cooling system and precision welding control system and high quality copper alloy electrodes with unique appearance.
b. The line wire and the weft wire of wire mesh welding machine are pre-straight and pre-cut.
c. We can design the welded wire mesh machine as your requirement.
d. Welding part can easily switch, which greatly improves the service life of machinery, maximum reduce the cost.
e. The wire mesh welding machine welding power comes from the cylinders. It's easy to control the welding pressure .
