5kw Automatic 5ft Width 440v Weld Mesh Making Machine
Automatic Five Feet 440V Wire Mesh Welding Machine
1. Product description
Automatic Five Feet 440V Wire Mesh Welding Machine is used for making wire mesh. This is automatic wire mesh welding machine line for the changeable diameter. PLC controlled system and touch screen make the machine line easy to operation. All the components used are with famous brand both aboard and at home. They guarantee the machine line has perfect performance and high quality as wall as long living life.
2. Technical parameter
| Model | Mesh width | Minimum mesh size (inch) | Wire diameter(mm) | Welding speed (rows/min) | Roll mesh length (m) | Other available mesh size (inch) |
| R- DHW | 6 feet | 1/2x1/2 | 0.45-0.85 | 90-120 | 130 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW | 6 feet | 1/2x1/2 | 0.6-1.3 | 90-120 | 110 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW | 6 feet | 1/2x1/2 | 0.8-1.6 | 80-90 | 100 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW | 6 feet | 1x1 | 0.45-0.85 | 90-120 | 130 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW | 6 feet | 1x1 | 0.6-1.3 | 90-110 | 110 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW | 6 feet | 1x1 | 0.8-1.6 |
90-110 |
100 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW | 6 feet | 1x1 | 1.4-2.6 | 80-90 | 80 | 1x2, 2x1, 2x2, 2x4 |
3. Application area
The Automatic Five Feet 440V Wire Mesh Welding Machine can be widely used in mining, petroleum, chemistry, food, medicine, machine manufacturing industry. It is used for machine protection for the above industries.
4. Advantages
a. To strengthen easy operation of machine,we use proximity switch between upper and lower welding heads,when cross wire doesn't reach,the machine will stop automatically.
b. We can provide detailed installation videos, manuals, electrical schemes, layouts to help your machine installation.
c. Raw materials can be galvanized wire, black wire and stainless steel wire.
