Galvanised Chicken 6feet Fence Mesh Welding Machine Full Automatic
Galvanized Automatic Chicken Fence Wire Mesh Welding Machine
1. Product description
Galvanized Automatic Chicken Fence Wire Mesh Welding Machine is used for making wire mesh. This kind of electric wire mesh welding machine adopts electrical and electronic synchronous control technique both separate-phase welding and welding time is composed of digital and integrated electric circuit.
2. Technical parameter
| Model | Mesh width | Minimum mesh size (inch) | Wire diameter(mm) | Welding speed (rows/min) | Roll mesh length (m) | Other available mesh size (inch) |
| R- DHW | 6 feet | 1/2x1/2 | 0.45-0.85 | 90-120 | 130 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW | 6 feet | 1/2x1/2 | 0.6-1.3 | 90-120 | 110 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW | 6 feet | 1/2x1/2 | 0.8-1.6 | 80-90 | 100 | 1/2x1, 1x1/2, 1x1, 2x2 |
| R- DHW | 6 feet | 1x1 | 0.45-0.85 | 90-120 | 130 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW | 6 feet | 1x1 | 0.6-1.3 | 90-110 | 110 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW | 6 feet | 1x1 | 0.8-1.6 |
90-110 |
100 | 1x2, 2x1, 2x2, 2x4 |
| R- DHW | 6 feet | 1x1 | 1.4-2.6 | 80-90 | 80 | 1x2, 2x1, 2x2, 2x4 |
3. Application area
Galvanized Automatic Chicken Fence Wire Mesh Welding Machine are widely used in construction. For example: the outer wall of the building, concrete and the high-rise buiding. It becomes the widely-using material in the modern time. For the using of this kind of wire mesh, the heat preservation and anti-cracking work of the modern construction can proceed favorablely.
4. Advantages
a.Transformer by Water cool.
b. The welding head is made of chromium-zirconium copper, with good electrical conductivity, hard material and abrasion resistance.
c. The mesh size is precise and the machine can be set the mesh width and mesh length according to customer’s requirement.
