Firestone W01-358-7406 Double Convoluted Air Spring Assembly Contitech FD 330-22 365 Goodyear 2B12-426
Firestone W01-358-7406 Contitech FD 330-22 365 Goodyear 2B12-426 Double Convoluted Air Spring Assembly
Cross reference
Air spring supplier: Firestone
Supplier number: W01-358-7406; W013587406; W01 358 7406; WO1-358-7406; WO13587406; WO1 358 7406
Air spring supplier: Contitech
Supplier number: FD 330-22 365; FD 330 22 365; FD 330-22365; FD330-22 365; FD330-22365; FD33022365
Air spring supplier: Goodyear
Supplier number: 2B12-426; 2B12 426; 2B12426
Goodyear Bellow Number: 578923309; 578 92 3 309; 578-92-3-309
Supplier number: 57007406
Specifications and Tecnical Parameters: 2B7406
|
1. Max. OD |
325mm |
|
2. Top plate Mounting Thread |
2pcs×1/2-13UNC |
| 3. The screw center distance | 157mm |
| 4. Bottom Blind nut | 2pcs×3/8-16UNC |
| 5. The distance between the two blind nuts on bottom plate | 157mm |
|
6. Cover plate diameter(width) |
231 mm |
|
7. Min. Height |
104mm |
|
8. Max. height |
305mm |
|
9. Bumper block/bumper |
Yes |
|
10. Belt loop/Girdle ring/Girdle hoop |
one piece |
| 11. Air Inlet | 1/4NPT |
The picture
