160.3mm Diameter 88538 Pneumatic Air Spring Model 20 Suspension Air Shock
Product Description:
The air spring features an F2 connection type, ensuring easy installation and compatibility with a wide range of vehicles. The F2 connection type is a standard connection type widely used in the automotive industry, making it easy to find compatible parts and accessories.
This air spring has a pressure range of 10-30 PSI, making it suitable for a wide range of applications. Whether you need a Pirelli airbag for your truck, van, or SUV, the air spring has you covered. The pressure range of this air spring is perfect for providing a comfortable and stable ride over rough terrain.
Features:
- Product Name: Torpress Air Spring
- Maximum Height: 265 Mm
- Weight of the parts: 5.0 Kg
- Specification: 33*33*40 Cm
- Shape: Cylinder
- OEM: 88538
- Features:
- Pirelli Air Cushion Suspension
- Pirelli Air Damper Shock
- Pirelli Air Damping System
Technical Parameters:
The top cover plate screw (nut) has 8 pieces with M8X1 tooth and a screw center distance of 160.3mm. The bottom cover plate screw (nut) also has 8 pieces with M8X1 tooth and a screw center distance of 160.3mm.
There is no gas hole or air inlet for this product.
The top cover plate has a diameter (width) of 179mm and the bottom cover plate has the same diameter as well.
The rubber bellows have a maximum diameter of 255mm and a natural diameter of 224mm. The working stroke ranges from 265mm to 80mm, while the compressed height is 80mm/3.12 inches. The design height of the bellows is between 178mm-203mm/7-8 inches. This product has a total of 20 bellows.
This product does not come with a bumper block.
This product includes one piece of girdle hoop.
Applications:
| The air spring is the perfect choice for industrial machines that require high-performance shock absorbers. It is specifically designed to replace Pirelli Air Damping Systems and Pirelli Pneumatic Shock Absorbers. It is a reliable and cost-effective solution for a wide range of industrial applications. |
| AIRSUSTECH 2H250180 M8 160.3 air spring is ideal for situations where the machine requires a stable and vibration-free operating environment. It is ideal for use in heavy machinery such as construction equipment, cranes and mining vehicles. |
