48V 200Ah BMS Solar Power Storage Cabinet 100kw 3000 Cycle
48V 200Ah Solar Power Storage Lithium Battery Storage Cabinets For 100kw Solar Storage
|
S/N |
Project |
General parameters |
|
|
1 |
Number of series |
16S2P |
|
|
2 |
Rated voltage |
51.2V |
|
|
3 |
Nominal Capacity (40°C , 0.5C) |
200 Ah |
|
|
4 |
Energy |
Normal energy (40°C , 0.5C) 10240 Wh Volumetric energy density 95Wh/L Gravimetric energy density 96Wh/kg |
|
|
5 |
Internal resistance (battery pack) |
≤100mΩ |
|
|
6 |
Self-discharge rate |
≤2%/month |
|
|
7 |
range of working temperature (≤95%R.H.) |
0～65℃ charge,20～65℃ discharge |
|
|
8 |
Storage temperature range (≤95%R.H.) |
-40～70℃ |
|
|
9 |
Positive and negative lead way |
Fence terminal 2P*2 |
|
|
10 |
Protective function |
Overcharge, over discharge, short circuit, overload, over temperature, etc. |
|
|
11 |
Shipment product charge |
50% power when delivery |
|
|
12 |
Packing material |
Carton |
|
|
13 |
Dimensions (W*D*H) |
445*430*222mm |
1.Key Features
♦ Longer Cycle Life : Offers up to 20 times longer cycle life and five times longer float/calendar life than lead acid battery , helping to minimize replacement cost and reduce total cost of ownership
♦ Lighter Weight : About 40% of the weight of a comparable lead acid battery . A " drop in" replacement for lead acid batteries
♦ Higher Power : Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity
♦ Wider Temperature Range : -20℃~60℃
♦ Superior Safety: Lithium Iron Phosphate chemistry eleminates the risk of explosion or combustion due to high impact overcharging or short circuit situation.
2.Advantages
Long cycle life,with around 3000 times on 80% DOD.
Support multiple communication pro-tools with RS485,RS232,CAN
Aluminum lithium battery cell with high performance.
Smart BMS with over charging/discharging protect.
High security performance,no fire,no explosion,no leakage.
Excellent electrical performance,low internal resistance,good charging/discharging.
