32U Cabinet 25kwh 48V 500AH Solar Storage Batteries With Communication
32U Cabinet 25kwh 48V 500AH Solar Storage Batteries With Communication
Production Name:
32U Cabinet 25kwh 48V 500AH solar home storage system Battery with communication RS485 RS232 CANBUS
The 25KWH battery is an ideal solution for residential storage applications, with standard 5U rack mount 48V / 100Ah 5 units, up to 90% usable capacity and 6,000 cycle-life warranty.
Vertical industry integration ensures more than 4500 cycles with 90% DoD or 6000 cycles with 80% DoD
Deliver up to 25KW with single module (25KWh)
Modular design gives the end customers the power of choice of capacity
Compatible with most of the available hybrid inverters
Simple buckle fixing minimize the installation time and cost
Compact and fashionable design fits in your sweet home environment
Bulit in BMS.Has multiple protection, RS485, RS232, CANBUS communication functions to ensure the reliability of the battery pack and achieve remote monitoring real time date of batteries.
Battery Cabinet can charge the home appliances and car,meet your at-one-stop electricity demand.
| Items | Specifications |
| Nominal Voltage | 48V |
| Nominal Capacity | 500Ah |
| Module Inside | 48V/51.2V 100AH |
| Configuration | 5 Units in parallel |
| Standard Charge Current | 0.2C-0.5C |
| Max. Charge Current | 1C |
| Battery management System (BMS) | BMS-16S |
| Continuous Discharge Current | 100A |
| Peak Discharge Current | 200A |
| Full Charged Voltage | 58.4V(3.65V per cell) |
| Charge Cut-off Voltage | 62.4V (3.9V per cell) |
| Discharge Cut-off Voltage | 40V (2.5V per cell) |
| Net Weight | 245kg |
| Dimensions | 32U |
| Connector | 4AWG |
| Operating Temperature |
Charging: 0°C ~ 45°C Discharging: -20°C ~ 55°C |
| Storage Temperature | (Recommended to store 20 ± 5°C for long term storage) |
| Cycle Life |
6000 times (80% of initial capacity at 0.2C rate, IEC Standard) |
s.
Company Introduction
Amazing Energy Limited(AE) was founded in 2009, draws on the experience of the main lithium battery industry and sub-industry. We committed to the revolution of the world’s lithium battery packs for different applications. And achieved a leading position in the field of starting battery, energy storage system, and smart battery.
We manufacture battery pack, including energy storage battery,lithium-ion battery pack,etc. We customize packs like start batteries, e-mobility batteries (scooter batteries, car batteries, forklift batteries, golf cart batteries, low-speed car batteries), marine batteries , energy storage battery (portable battery / home / commercial / industrial energy storage / stationary battery / UPS, custom battery pack, etc.).
We are willing to share experience with customers interested in the battery business, while selling products and battery equipment, teaching customers battery knowledge, assembly process, testing methods, battery maintenance skills, etc., and we would like to share technology, on-site guidance for customers who plan to build factory and production line etc in their countrie
