Waves Glazed Roof Tile Forming Machine 3 Kw 1200mm 12meters/Min

More Waves Glazed Roof Tile Forming Machine

Product intruduction:

1. Simple construction. The paving speed is fast and the construction cost is low.

2. Economical. Bright color, strong load-bearing, heat preservation, fire prevention

    and waterproof performance.

3. Advanced technology. The line adopts continuous coiled material production.

    After cold bending, the cut parts are formed at one time. The shape is regular

    and the length is consistent.

4. High reliability. The technical parameters of hydraulic and pneumatic electrical

    systems of the line are applicable to materials.

Technical parameters:

Power of machine:3kw
Power of cutting:3kw
Coil width:1200mm
Thickness of material to form:0.3-0.8mm
Roll stations:13
Type of cutting:hydraulic cutting
Speed of line:0-12meters/min
Diameterofshaft:70mmsolid
Sizes of chain:single one inch
Material of rollers:C45 steel,with heat treatment
Material of blade:cr12
Hardnessofblade:HRC58°-60°
Computer control with frequency
