Hyundai 31Q6 40022 31Q6 40020 Track Gearbox Final Drive Withour Motor

Price Negotiable
Price: USD 939-995/PC
MOQ: 1PC
Delivery Time: 1-3 working days
Brand: PNC
Product Description

Hyundai 31Q6 40022 31Q6 40020 Track Gearbox Final Drive Withour Motor​



R210LC-9 Hyundai Travel Gearbox 31Q6-40020 Final Drive Withour Motor



Description

R210LC-9 Travel Reducer, R210-7 Final Drive withour motor, Hyundai Gearbox

Application

Hyundai R160LC-9S Excavator

Model

R210LC-9, R210-7, R160LC-9S, R180LC-9S

Part No.

31Q6-40020, 31Q6-40021, 31Q6-40022, 31N6-40040, 31N6-40041

Quality

China made, OEM quality

Weight

280-300 kgs

Packing

heavy items pack into wooden

MOQ

1PC

Lead time

About 1-3 working days

Payment

TT, Western union, Paypal, Paysend, RMB

Warranty

3 Months

Shipping Port

Huangpu Old Port, Shenzhen Yantian,Guangzhou






Parts on group R210-9 TRAVEL REDUCTION GEAR (TYPE 1):



Pos.

Part No

Qty

Parts name

Comments

*.

@

[1]

TRAVEL MOTOR ASSY

SEE 4150

*.

@

[1]

TRAVEL MOTOR ASSY

SEE 4150

*-2.

31Q6-40020

[1]

TRAVEL REDUCTION GEAR



*-2.

31Q6-40021

[1]

TRAVEL REDUCTION GEAR



*-2.

31Q6-40022

[1]

T/REDUCTION GEAR



N1.

XKAQ-00217

[1]

HOUSING



2.

XKAQ-00218

[2]

BEARING-MAIN



2.

XKAQ-00986

[2]

BEARING-MAIN



3.

XKAQ-00219

[1]

SEAL-FLOATING



4.

XKAQ-00220

[1]

SHIM



5.

XKAQ-00221

[1]

RETAINER



6.

XKAQ-00222

[12]

BOLT-HEX



7.

XKAQ-00223

[2]

PIN-PARALLEL



8.

XKAQ-00224

[1]

GEAR-RING



9.

XKAQ-00225

[1]

COUPLING



9.

39Q6-42170

[1]

COUPLING



10.

XKAQ-00226

[1]

CARRIER 2 ASSY



10-1.

XKAQ-00227

[1]

CARRIER 2



10-2.

XKAQ-00228

[4]

GEAR-PLANET 2



10-3.

XKAQ-00229

[8]

BEARING-NEEDLE 2



10-4.

XKAQ-00230

[8]

WASHER-THRUST



10-5.

XKAQ-00231

[4]

PIN 2



10-6.

XKAQ-00232

[4]

PIN-SPRING



10-7.

XKAQ-00208

[2]

RING-THRUST



11.

XKAQ-00653

[1]

CARRIER ASSY 1



11-1.

XKAQ-00234

[1]

CARRIER 1



11-2.

XKAQ-00235

[1]

GEAR-SUN 2



11-3.

XKAQ-00236

[1]

RING-RETAINING



11-4.

XKAQ-00237

[3]

GEAR-PLANET 1



11-5.

XKAQ-00238

[3]

BEARNG-NEEDLE 1



11-6.

XKAQ-00657

[6]

WASHER-THRUST



11-7.

XKAQ-00240

[3]

PIN 1



11-8.

XKAQ-00241

[3]

PIN-SPRING



11-9.

XKAQ-00655

[1]

PIN-SPRING



12.

XKAQ-00402

[1]

GEAR-SUN 1



12.

XKAQ-00795

[1]

GEAR-SUN 1



13.

XKAQ-00243

[1]

COVER



14.

XKAQ-00214

[1]

PAD



15.

XKAQ-00244

[20]

BOLT-SOCKET



16.

XKAQ-00245

[2]

SCREW-HEX SOCKET



17.

XKAQ-00246

[3]

PLUG-HYDRAULIC



18.

XKAQ-00247

[3]

O-RING



19.

XKAQ-00248

[1]

NAME PLATE



19.

XKAQ-00990

[1]

NAME PLATE



N.

@

[AR]

NOT SUPPLIED PARTS



More Hyundai Travel Reduction Gear, Travel Gearbox we do:



Part No.

Name

31E6-42000BG

Travel reducer

XKAH-00367

Travel reducer

31N6-40040, 31N6-40041, 31N6-40050

Travel reducer

39Q6-42100

Travel reducer

39Q6-42100

Travel reducer

XKAH-00901

Travel reducer

XKAH-01577, 39Q7-42100, 31Q7-40060

Travel reducer

31Q7-40060

Travel reducer

31N8-40070

Travel reducer

31N8-40071

Travel reducer

31N8-40072

Travel reducer

31Q9-40021

Travel reducer

31Q9-40022/23

Travel reducer

31Q9-40030

Travel reducer

31Q9-40023

Travel reducer

31N8-40070

Travel reducer

31N8-40071

Travel gearbox

31N9-40022

Travel gearbox

31Q9-40021

Travel gearbox

XKAH-01061

Travel gearbox

XKAY-01704

Travel gearbox

34E7-02500

Travel gearbox



Payment &Packing &Shipping:



A). TT transfer, Western Union, Paypal, Moneygram are acceptable.



B). Light goods inner box is neutral white with an strong outer box.Heavy goods wooden with standard packing.If you have legally registered patent,

we can pack the goods in your branded boxes after getting your authorization letters.



C). Delivery time: depends on items you buy, most electric parts can shiped within 1-3 working days.



D). DHL /Fedex /UPS /TNT/ARMEX/SF Express ,etc. normal express shipping way for small cargo.Russia,Kazakhstan, Ukraine Russia Special Line,

Bangladesh,Myanmar,Vietnam ect, competitive shipping way no need you do customs clearance.Door to Door.



Warranty Statement:



1. Warranty Type: We will replace the product which have quality problem.


2. Warranty Period: Supply 3 months warranty for the products from the date of arrival. Customer should check the items according to the order list after arrival.

Contact with us and offer the data, photos of the problem items



3. You need to pay for the replacement charge for following condition:

* Wrong Order from customer.
* Natural Disasters cause the damage.
* Error installation, improper use.
* The machine and reducer work over time and over load.
* Lost by any condition.
* Human element destroyed.
* Corrode with rust during stock and running.
* Warranty Expired.
