MMS6210 EPRO Dual Channel Shaft Displacement Monitor
Price:
$1000
MOQ:
1 Piece
Delivery Time:
3-5 work days
Brand:
Emerson
Product Description
MMS6210 EPRO Dual Channel Shaft Displacement Monitor
Description:
The Dual Channel Shaft Displacement Measuring Module MMS 6210 measures shaft movements such as:axial shaft positions at shafts ends, rectangular or conical discs also in tandem configurations, differential and thermal expansions as well as radial shaft positions and shaft bendings.
Channel clear/circuit fault sensing system; the internal modul supervision circuitry continuously supervises the following functions:
- Sensor signal is within a preset window.
- Cabling between sensor and modul is ok (no short circuit, no break).
- System supply voltages are within preset windows.
- Configuration and parameter settings are correct.
- Measuring range not overloaded.
Product Details:
| Brand Name | EPRO |
| Model | MMS6210 |
| Catalog | MMS6210 |
| Origin | Germany |
| Dimension | 16*16*12cm |
| Weight | 1kg |
| HS Code | 8537101190 |
| Payment | T/T |
| Sales Price | $1000 |
| Warranty | 12 months |
| Lead time | 3-5 work days |
Additional Information:
| Features |
| Part of the MMS 6000 System |
| Replaceable during operation;stand alone use possible,redundant supply inputs |
| Extended selfchecking facilities;built in sensor-self-test facilities;password protected operating levels |
| For use with eddy-current type transducer systems PR 6422 /...to PR 6426 /... with CON /... |
| Readout of all measured data via RS 232/RS 485 |
| Built-in linearisation facilities |
| RS 485 interface for communication with epro's Analysis and Diagnostic System MMS 6850 |
Datasheet Link:
