Bently Nevada 330103-00-15-10-02-00 3300XL 8 Mm Proximity Probes Without Armour
Bently Nevada 330103-00-15-10-02-00 3300XL 8 Mm Proximity Probes Without Armour
Additional Information:
| Specifications | |
| Standard cable | 75Ω triaxial, fluoroethylene propylene (FEP) insulated probe cable in the following total probe lengths: 0.5, 1, 1.5, 2, 3, 5, or 9 meters. |
| Extended Temperature Range cable | 75Ω triaxial, perfluoroalkoxy (PFA) insulated probe cable in the following total probe lengths: 0.5, 1, 1.5, 2, 5, or 9 meters. |
| Armor (optional on both) | Flexible AISI 302 or 304 SST with FEP outer jacket. |
| Tensile Strength (Maximum Rated) |
330 N (75 lbf) probe case to probe lead. 270 N (60 lbf) at probe lead to extension cable connectors. |
| Connector Material | Gold-plated brass or goldplated beryllium copper. |
Description:
3300 XL 8 mm probes are designed to seal differential pressure between the probe tip and case. The probe sealing material consists of a Viton® O ring. Probes are not pressure tested prior to shipment.Contact our custom design department if you require a test of the pressure seal for your application.
It is the responsibility of the customer or user to ensure that all liquids and gases are contained and safely controlled should leakage occur from a proximity probe.
Performance characteristics apply to systems that consist solely of 3300 XL 8 mm components. The system accuracy and interchangeability specifications do not apply to transducer systems that are calibrated to any target other than our AISI 4140 steel target.
Product Details:
| Brand Name | Bently Nevada |
| Model | 3300XL |
| Ordering information | 330103-00-06-10-02-00 |
| Catalog | 3300XL |
| Origin | United States (USA) |
| Dimension | 16*16*12cm |
| Weight | 1kg |
| HS Code | 8537101190 |
| Payment | T/T |
| Sales Price | $500 |
| Warranty | 12 months |
| Lead time | 3-5 work days |
Datasheet Link:
