MSDS certified 1.85 Wh 3.7 V 500mah Lipo Battery GPS Tracker Battery
Price:
negotiable
MOQ:
10PCS/ORDER
Delivery Time:
3-5days
Brand:
Purple Horn
Product Description
Key Specifications/Special Features:
3.7V 500mAh Lithium-polymer battery with PCB and wires
Specifications
1. Model: 503035-500mAh
2. Battery type: Li-Po battery
3. Nominal voltage: 3.7V
4. Charge voltage: 4.25V
5. Nominal capacity: 500mAh
6. Dimensions: 5.2x30.5x37.5mm with PCM
7. Standard discharging current: 0.2C
8. Maximum charging current: 1C
9. Standard charging current: 0.2C
10. Rap charging current: 1C
11. Self-discharge: <2%/month
12. Charging temperature: 0° to 45°C
13. Discharging temperature: -20 to 75°C
14. Storage temperature:
Specifications
1. Model: 503035-500mAh
2. Battery type: Li-Po battery
3. Nominal voltage: 3.7V
4. Charge voltage: 4.25V
5. Nominal capacity: 500mAh
6. Dimensions: 5.2x30.5x37.5mm with PCM
7. Standard discharging current: 0.2C
8. Maximum charging current: 1C
9. Standard charging current: 0.2C
10. Rap charging current: 1C
11. Self-discharge: <2%/month
12. Charging temperature: 0° to 45°C
13. Discharging temperature: -20 to 75°C
14. Storage temperature:
- -20 to 45°C (within 1month)
- -20 to 40°C (within 3month)
- -20 to 35°C (within 6month)
15. Certifications: RoHS Directive, UL, MSDS, REACH, UN 38.3
16. Weight: approximately 12g
17. Applications: GPS tracker, Bluetooth earphones use
Size of Lithium-polymer battery can be custom made, we have the advantage making special Li-Po battery such as extremely thin Li-Po battery (1.5mm), high-temperature Li-Po battery, low-temperature Li-Po battery, special shape Li-Po battery (round)
Product Description
| Brand: | WLY | Model: | 3.7v 500mah Battery |
| Type: | Li-Polymer | Charge Current: | 0.2C Standard/1C |
| Capacity: | 500 mAh | Voltage: | 3.7-4.2V |
| Energy: | 1.85Wh | Size: | 90*20*32mm |
| Impendence: | 200 m&OPurple Horn; | Warranty Time: | 12 Months |
| Cycle life: | Around 500 Times | Working Temperature: | Charge: 0~45 Degree, Discharge: -10~50 Degree |
