HNBR jack hammer seal kit 3315 2905 90 SB152 Hydraulic Breaker Spare Parts
3315290590 Atlas Copco SB152 Hydraulic Breaker hammer Seal Kit 3315 2905 90 SB152 atlas copco hydraulic breaker parts
Model:Atlas Copco SB152 Hydraulic breaker Repair service seal kit
Part Name:Hydraulic breaker seal kit, Hydraulic hammer seal kit
Tool:50MM
Part Number:3315 2905 90
Material:TPU+HNBR+PTFE
Packaging Details: bag or box +carton
CertifiCATEEion: IOS 9001
Delivery Time: 2-5days upon payments confirmed
Position:Atlas Copco Hydraulic Breaker Systerm
Brand:BULLDOG,OEM or as Required
Payment Terms: TT/Paypal/WEST UNION
Supply Ability: 500
MOQ:1set
Parts list
| NO. | product name | Quantity | Part number |
| 1 | Breaker body | 1 | - |
| 2(3-5) | Bushing, complete | 1 | 3315 3539 80 |
| 3 | Bushing | 1 | - |
| 4 | Scraper ring | 1 | 3315 3564 00 |
| 5 | O-ring | 4 | 0663 2102 89 |
| 6 | Stop ring | 1 | 3315 2918 00 |
| 7 | Plug | 1 | 0686 1000 09 |
| 8 | Hexagon socket plug | 6 | 0686 6442 07 |
| 9 | Water nozzle, option | 1 | 3315 3952 00 |
| 10 | Lock pin | 1 | 3315 2930 00 |
| 11 | Spring pin, option | 1 | 0108 1691 26 |
| 12 | Tool retainer | 2 | 3315 1470 00 |
| 13 | Lock buffer | 1 | 3315 1419 00 |
| 14 | Hexagon socket plug | 4 | 0686 3718 01 |
| 15 | Coil spring | 1 | 3315 2933 00 |
| 16 | Diaphragm support | 1 | 3315 2889 00 |
| 17 | Diaphragm | 1 | 3315 2890 00 |
| 18 | Accumulator house | 1 | 3315 2824 00 |
| 19 | Hexagon socket screw | 8 | 0211 1965 34 |
| 20 | Hexagon socket plug | 1 | 0686 3718 05 |
| 21 | Seal ring | 1 | 3115 3290 02 |
| 22 | O-ring | 1 | 0663 2120 00 |
| 23 | Charge valve | 1 | 3315 3660 00 |
| 24 | O-ring | 1 | 0663 2114 00 |
| 25 | Parallel pin | 1 | 0101 4140 00 |
| 26(27-29) | Nipple, complete | 1 | 0570 7000 03 |
| 27 | Nipple | 1 | - |
| 28 | Seal ring | 1 | 0664 0000 03 |
| 29 | O-ring | 1 | 0663 9055 01 |
| 30 | Cap | 2 | 0570 7000 19 |
| 31 | Valve cover | 1 | 3315 3640 00 |
| 32 | O-ring | 2 | 0663 2114 90 |
| 33 | Control valve | 1 | 3315 2919 00 |
| 34 | Seal ring | 2 | 0665 0900 14 |
| 35 | Plug | 1 | 3315 3050 00 |
| 36(37-39) | Pressure relief valve, complete | 1 | 3315 3350 00 |
| 37 | Pressure relief valve | 1 | - |
| 38 | O-ring | 1 | 0663 9032 01 |
| 39 | O-ring | 1 | 0663 9054 01 |
| 40(41-43) | Restrictor standard, complete | 1 | 3315 3695 51 |
| 41 | O-ring | 1 | 0663 9054 01 |
| 42 | O-ring | 1 | 0663 9032 01 |
| 43 | Restrictor | 1 | - |
| 44 | Grease nipple | 1 | 0544 2153 00 |
| 45 | Wiper | 1 | 0665 9099 54 |
| 46 | Piston rod seal | 1 | 0665 0701 31 |
| 47 | O-ring | 5 | 0663 2114 56 |
| 48 | O-ring | 1 | 0663 2106 31 |
| 49 | Liner | 1 | 3315 2913 00 |
| 50 | O-ring | 4 | 0663 2100 53 |
| 51 | Piston | 1 | 3315 2917 00 |
| 52 | Piston rod seal | 1 | 0665 0701 32 |
| 53 | Back head | 1 | 3315 2939 00 |
| 54(55-56) | Check valve, complete | 1 | 3315 2448 81 |
| 55 | Check valve | 1 | - |
| 56 | Valve rubber | 1 | 3315 2808 00 |
| 57 | Hexagon head screw | 8 | 0147 1481 03 |
| 58 | Base plate, option | 1 | 3315 3043 00 |
| 59(60-61) | Set of eight screws, complete | 1 | 3315 2964 90 |
| 60 | Screw | 8 | - |
| 61 | Nut | 8 | - |
Parts exploded view
